CRD Water Infrastructure Map

September 15, 2020Page 7761 section

Map showing water mains, hydrants, and valves in the vicinity of Island Highway and Helmcken Road.

Scale 1:992Capital Regional District (CRD)

Map Title

Aerial map showing water utility infrastructure at the intersection of Helmcken Rd, Island Hwy, and Stewart Ave. The map displays various pipe types and sizes including 200 PVC, 200 DI, 250 DI, 150 PVC, 200 AC, and 813 ST. Specific hydrants are labeled VRFD061, VRFD101, VRFD190, VRFD012, and VRFD077. An air release valve is also indicated.
Aerial map showing water utility infrastructure at the intersection of Helmcken Rd, Island Hwy, and Stewart Ave. The map displays various pipe types and sizes including 200 PVC, 200 DI, 250 DI, 150 PVC, 200 AC, and 813 ST. Specific hydrants are labeled VRFD061, VRFD101, VRFD190, VRFD012, and VRFD077. An air release valve is also indicated.

Legend

Facility or Station

  • Disinfection Facility
  • Injection
  • Pump Station
  • Storage Facility

Bulk Meter

  • Distribution Balancing Meter
  • Supply Bulk Meter

Control Valve

  • Altitude Valve
  • Check Valve
  • Pressure Control Station

Hydrant

  • Bulk Water Station
  • Hydrant
  • Standpipe

System Valve

  • Air Release, True
  • Flush, True
  • Lateral Valve, False; Valve, False
  • Lateral Valve, True; Valve, True
  • Valve Vault, False
  • Valve Vault, True

Fitting

  • Cap
  • Reducer

Map Information

  • Scale: 1: 992
  • Coordinate System: NAD_1983_UTM_Zone_10N
  • Copyright: © Capital Regional District

Important: This map is for general information purposes only. The Capital Regional District (CRD) makes no representations or warranties regarding the accuracy or completeness of this map or the suitability of the map for any purpose. This map is not for navigation. The CRD will not be liable for any damage, loss or injury resulting from the use of the map or information on the map and the map may be changed by the CRD at any time.

Notes

Page 776
Extracted from: 2020 09 15 Committee of the Whole Agenda - Agenda - Pdf
