Hydrant Curve for VRFD077 on Island Hwy

September 15, 2020Page 7771 section

Technical graph showing the available flow and pressure for fire hydrant VRFD077.

VRFD077Island Highway

Hydrant Curve for VRFD077 on Island Hwy

A line graph titled "Hydrant Curve for VRFD077 on Island Hwy" showing Available Flow (L/s) on the horizontal x-axis ranging from 0 to over 900, and a vertical y-axis with values ranging from 0 to 100. The curve starts at approximately 83 on the y-axis at zero flow and trends downward as flow increases.
A line graph titled "Hydrant Curve for VRFD077 on Island Hwy" showing Available Flow (L/s) on the horizontal x-axis ranging from 0 to over 900, and a vertical y-axis with values ranging from 0 to 100. The curve starts at approximately 83 on the y-axis at zero flow and trends downward as flow increases.
Page 777
