Post Development Site Plan - Parking Level P1

September 15, 2020Page 7811 section

Plan showing the proposed underground parking layout and final pervious area after development.

Pervious Area: 240 m2 (13%)39 total stalls (Commercial + Residential P1)

Parking Plan - Level P1

Architectural drawing showing the post-development parking layout for Level P1, including commercial and residential stalls, bicycle storage areas, ramps, and site statistics.
Architectural drawing showing the post-development parking layout for Level P1, including commercial and residential stalls, bicycle storage areas, ramps, and site statistics.

Commercial Parking P1

  • Standard Stalls: 5
  • Small Stalls: 5
  • Total Stalls: 5 + 5 = 10

Residential Parking P1

  • Standard Stalls: 8
  • Small Stalls: 20
  • Disability Stalls: 1
  • Total Stalls: 8 + 20 + 1 = 29

Site Features and Circulation

  • Bicycle Storage:
    • Dedicated area for 21 Bicycle Stalls.
    • Multiple bicycle stall areas located centrally and in the lower-right corner.
  • Access:
    • Ramp from Level 1 (15.0% slope down / 10.0% slope on).
    • 4.4% slope down in the main driveway.
    • Overhead gate access to residential parking.
    • Elevator and Exit Stair access.
    • End of Trip facilities.
  • Key Elevations:
    • EL. 19.36 m
    • EL. 19.91 m
    • EL. 19.96 m
    • EL. 20.36 m
    • EL. 20.96 m

Post Development Statistics

  • Site Area: 1,853 m2
  • Pervious Area: 240 m2 (13%)
