Site Plan - 37 Stoneridge Dr

April 9, 2019Page 951 section

Draftsman sketch showing the dwelling footprint and the proposed deck area relative to the 6m and 8m setbacks.

2 APPROVAL OF AGENDA
8m and 6m setback linesStoneridge Drive

37 STONERIDGE DRIVE

Site plan for 37 Stoneridge Drive showing a dwelling under construction, a porch, a walkway, and a proposed deck area with various property dimensions and setback annotations.
Site plan for 37 Stoneridge Drive showing a dwelling under construction, a porch, a walkway, and a proposed deck area with various property dimensions and setback annotations.

Plan Annotations:

  • Property Address: 37 STONERIDGE DRIVE
  • Main Structure: dwelling under construction
  • Other Features:
    • porch
    • WALKWAY
    • Lot 36
  • Proposed Deck Note: Deck surface will be permeable 1.5 - 2" x 6" wood or composite deck boards
  • Setbacks and Indicators:
    • 6m SETBACK
    • 8M
    • EXISTING

Dimensions and Measurements:

  • Property Boundary Measurements: 43.781, 19.180, 35.332, 13.754
  • Building and Feature Dimensions:
    • 13.72
    • 10.17
    • 9.42
    • 8.84m
    • 7.32m
    • 6.71m
    • 5.87
    • 4.88m
    • 4.66
    • 3.63
    • 3.19
    • 3.18
    • 3.12
    • 2.87
    • 2.74
    • 2.71
    • 2.61
    • 2.60
    • 2.04
    • 1.52m (multiple instances)
    • 1.51
    • 1.36
    • 1.24m
    • 1.23 (multiple instances)
