Construction Plans - 37 Stoneridge Dr

April 9, 2019Page 961 section

Technical architectural drawing of the proposed deck structure attached to the living room and dining room area.

2 APPROVAL OF AGENDA
3 - 2X10" Beam8.84 M length

Architectural Deck Plan

Detailed architectural plan showing the layout of a living room, dining room, kitchen, and an existing deck, along with proposed deck extensions. The diagram includes structural details for beams, joists, posts, and concrete footings, along with various dimensions in feet and meters.
Detailed architectural plan showing the layout of a living room, dining room, kitchen, and an existing deck, along with proposed deck extensions. The diagram includes structural details for beams, joists, posts, and concrete footings, along with various dimensions in feet and meters.

Room Layout

  • Living Room
  • Dining Room
  • Kitchen
  • EXISTING DECK

Structural Specifications

  • Ledger: Ledger fixed to exterior wall to support beam span (27'-0")
  • Beams: 3 - 2X10" Beam
  • Joists: 2x8" joists @ 16" o/c
  • Posts and Piers: 6X6" S-P-F WOOD POST ON 8X8" CONCRETE PIER — MIN. 6" ABOVE GRADE
  • Footings: 24X24X8" CONCRETE PAD FOOTING (TYP.)
  • Deck Surface: Deck surface will be permeable 1.5-2X6" wood or composite deck boards and will allow for drainage.

Dimensions

  • 16'-0" / 4.88 M
  • 27'-0"
  • 9'-0" (typical beam spacing)
  • 6'-11"
  • 6'-11 5/16"
  • 4'-11 3/4"
  • 29'-1 1/16" / 8.84 M
  • 31'-0" / 9.45 M
Page 96
