Deck Construction Cross-Section Details

April 9, 2019Page 971 section

Engineering cross-section showing structural details for guards, beams, and footings.

2 APPROVAL OF AGENDA
24x24x8" Conc. Pad Footing6x6" Post
Technical diagram of deck construction details, showing cross-sections for guardrails, ledger attachment, joists, beams, and concrete pier footings.
Technical diagram of deck construction details, showing cross-sections for guardrails, ledger attachment, joists, beams, and concrete pier footings.

Deck Construction Details and Specifications

  • GUARD SHALL BE "NON-CLIMBABLE" AND NO OPENINGS SHALL BE GREATER THAN 4" (BCBC 9.8.8.5 / 9.8.8.6)
  • Guardrail Dimensions:
    • 3'-6" (Total guard height)
    • MAX. 5" (Gap between deck surface and bottom of guardrail)
    • MAX. 4" (Width of openings/picket spacing)
  • Flashing and Drainage:
    • FLASH 2" MIN. VERTICALLY BEHIND BUILDING PAPER
    • SLOPE DECK TO DRAIN AFTER SHRINKAGE
    • PROVIDE DRIP FLASHING IF DECK HAS A FREE-DRAINING SURFACE
  • Framing and Support:
    • LEDGER: LAG-BOLT OR THROUGH-BOLT TO EXIST. FRAMING
    • JOIST HANGER
    • X __ BEAM
    • 6x6" POST
    • POST SADDLE WITH ANCHOR BOLT
  • Fasteners:
    • USE ONLY APPROVED CORROSION-RESISTANT FASTENERS WITH PRESSURE TREATED ELEMENTS.
  • Footing and Grade:
    • 8" MIN. (Clearance between finished grade and bottom of post/top of pier)
    • FINISHED GRADE
    • MIN. 18" BELOW GRADE (Minimum depth of footing)
    • 8x8" OR 9" Ø CONC. PIER
    • 24x24x8" CONC. PAD FOOTING
