Committee of the Whole/Documents/Attachment 6. New Site Concept
Appendix

Attachment 6. New Site Concept

April 9, 2019Page 1361 section

Revised site plan showing building locations and covenant areas.

2 APPROVAL OF AGENDA
Covenant Area 11067 SQ M21.3% Covenant Percentage

Attachment 6: New Site Concept

Site plan diagram illustrating a proposed residential development layout featuring multiple building clusters, parking facilities, a play park area, and site topography labels. The site is bordered by the Trans Canada Highway and Thetis Lake Regional Park.
Site plan diagram illustrating a proposed residential development layout featuring multiple building clusters, parking facilities, a play park area, and site topography labels. The site is bordered by the Trans Canada Highway and Thetis Lake Regional Park.

Site Data

  • COVENANT AREA: 11067 SQ M
  • OVERALL PARCEL (CRD INCLUDED): 51929 SQ M
  • COVENANT PERCENTAGE: 21.3%
  • OVERALL PARCEL (EXCLUDING CRD): 42585 SQ M
  • COVENANT PERCENTAGE: 26.0%
  • SCALE: 1:500

General Site Information

  • Proposed Play Park: ±353 SQ M (TBD)
  • Surrounding Context:
    • TRANS CANADA HIGHWAY
    • THETIS LAKE REGIONAL PARK
    • REMAINDER 36 PLAN 748
    • SECTION 97
    • ROAD PLAN VIP62157

Site Elevations and Reference Points

The following numerical labels and elevation points are indicated across the site plan:

  • 43.3
  • 43.9
  • 44.0
  • 44.2
  • 44.3
  • 44.8
  • 45.2
  • 45.75
  • 46.0
  • 46.81
  • 49.13
  • 50.72
  • 51.5
  • 51.8
  • 51.88
  • 52.1
  • 53.46
  • 55.78
  • 58.15
  • 60.54
  • 62.94
  • 63.45
  • 63.72
  • 65.11
  • 65.34
  • 67.18
  • 67.71
  • 68.97
  • 69.44
  • 69.93
  • 70.18
  • 70.31
  • 70.36
