APPENDIX A: ROADWAY MODIFICATION QUEUE LENGTH IMPACTS

QUEUE LENGTHS (PM PEAK HOUR) EXISTING AND PROPOSED LANING HELMCKEN RD / BURNSIDE RD

Project Information

Project No: 2497.B01
Date: MAR 27, 2019
Address: #501, 740 - Hillside Ave, Victoria, BC V8B TZ4
Designed: TV
Drawn: TV
Scale: 1:2,500

Map Sections

EXISTING QUEUE LENGTHS
ESTIMATED 2028 POST DEVELOPMENT QUEUE LENGTHS WITH PROPOSED LANING UPGRADES

Legend

95% QUEUE LENGTHS - EXISTING CONDITIONS (indicated by red lines)
95% QUEUE LENGTHS- PROPOSED LANE CHANGES WITH 2028 BACKGROUND VOLUMES (indicated by blue lines)
ADDITIONAL QUEUE LENGTH DUE TO PROPOSED DEVELOPMENT TRAFFIC (indicated by yellow dashed lines)

Aerial view of the Helmcken Rd and Burnside Rd intersection showing queue impacts

Aerial view of the curve on Burnside Rd east of the intersection

Aerial view of the shopping center area and parking lot adjacent to the intersection

Aerial view of the Helmcken Rd approach to the intersection

Key Locations and Roadways Noted on Map

PROPOSED EAGLE NEST DEVELOPMENT
WATKISS WAY
HELMCKEN RD
BURNSIDE RD
