Appendix
Eagle Nest Residences - Section
March 10, 2020Page 2811 section
Cross-section architectural drawing showing building heights and underground parking levels.
Building 1 height: 19.2 mBuilding 2 height: 14.8 mTwo levels of underground parkade (P1, P2)
Eagle Nest Residences - 3 Helmcken Road, Victoria, BC
Section
This architectural section drawing illustrates the vertical profile of Building 1 and Building 2, including floor levels, building heights, and underground parking.
Legend
| Category | Description |
|---|---|
| 1 Bed | Light Purple |
| 2 Bed | Light Green |
| Common Areas | Yellow |
| Parkade | Light Grey |
Elevation and Height Data
Building 1
- Roof: 48.1 m
- L6: 44.0 m
- L5: 40.9 m
- L4: 37.8 m
- L3: 34.7 m
- L2: 31.6 m
- L1 Lobby: 28.5 m
- Average Grade: 28.9 m
- Building Height: 19.2 m
Building 2
- Roof: 41.9 m
- L4: 37.8 m
- L3: 34.7 m
- L2: 31.6 m
- L1 Lobby: 28.5 m
- Average Grade: 27.1 m
- Building Height: 14.8 m
Parkade Levels
- P1: 25.0 m
- P2: 21.5 m
Project Details
- Project Name: Eagle Nest Residences
- Address: 3 Helmcken Road, Victoria, BC
- Drawing Title: Section
- Drawing No.: A501
- Revision No.: 2
- Date: 27 FEB 2020
- Scale: 1:150
- Drawn By: NLC
- Checked By: RAW
- Project Number: 1827
- Drawing File: 1827 A501 Site Section.vwx
Revision History
| Rev | Date | Description |
|---|---|---|
| 1 | 17 SEP 2018 | ISSUED FOR REZONING |
| 2 | 22 JAN 2020 | ISSUED FOR REZONING |
| 2 | 27 FEB 2020 | ISSUED FOR REZONING |
NOTE: All dimensions are shown in millimeters.
Office Locations
- Victoria Office: 977 Fort Street, Victoria BC V8V 3K3 | T 250-658-3367
- Nanaimo Office: 102 - 5190 Dublin Way, Nanaimo BC V9T 0H2 | T 250-585-5810
ISSUED FOR REZONING
Page 281
