Architectural 3D perspective drawings of the proposed development from various vantage points.

9.2.3 a) Rezoning - 1449 Burnside Road West (Eagles Nest)
Bird's eye views looking North East and North West

Eagle Nest Residences

3 Helmcken Road Victoria, BC

Perspectives

Perspective at Burnside and Helmcken
Perspective at Burnside and Helmcken
Bird's eye perspective looking north east
Bird's eye perspective looking north east
Perspective looking north from Burnside
Perspective looking north from Burnside
Bird's eye perspective looking north west
Bird's eye perspective looking north west

ISSUED FOR REZONING

Rev Date Description
1 17 SEP 2018 ISSUED FOR REZONING
2 22 JAN 2020 ISSUED FOR REZONING
2 27 FEB 2020 ISSUED FOR REZONING

Project Information

  • Plot date: 27 FEB 2020
  • Drawn by: RAW
  • Scale: N.T.S.
  • Drawing file: 1827 A100 Site Plan.vwx
  • Checked by: EDS
  • Project number: 1827
  • Drawing no: A602
  • Revision no: 2

Architect Information dHKarchitects

Victoria Office 977 Fort Street Victoria BC V8V 3K3 T 1 250 658 3367

Nanaimo Office 102 - 5190 Dublin Way Nanaimo BC V9T 0H2 T 1 250 585 5810

NOTE: All dimensions are shown in millimeters.
