Eagle Nest Residences - Landscape Sections
Landscape cross-sections showing the interface between buildings, private patios, and the public sidewalk.
Project Information
Client: INVICTUS COMMERCIAL INVESTMENT CORP (ICIC) 605 DOUGLAS STREET, SUITE 204 VICTORIA, BC
Project: EAGLES NEST RESIDENCES HELMCKEN & WEST BURNSIDE ROADS VIEW ROYAL, BC
Landscape Planning & Design: Murdoch de Greeff Inc. 200 - 524 Culduthel Road Victoria, BC V8Z 1G1 Phone: 250.412-2891 Fax: 250.412-2892
Project Details:
- Project No.: 118.29
- Scale: AS SHOWN @ 24"x36"
- Drawn by: JD
- Checked by: SM/PdG
- Sheet Title: Landscape Sections
- Sheet No.: L1.02
Revision History
| rev no | description | date |
|---|---|---|
| 1 | REZONING | SEPT. 14, 2018 |
| 2 | REZONING REV.1 | JUN. 25, 2019 |
| 3 | REZONING REV.2 | JAN. 22, 2020 |
NOT FOR CONSTRUCTION
Landscape Sections
1 SECTION 1 THROUGH WESTERN LANDSCAPE
Scale: 1:100
This section illustrates the western property edge featuring retained existing trees and new understory planting adjacent to the building.
- Retained trees and landscape
Building section profile with tiered balconies
Tall narrow conifer tree
Conical evergreen conifer tree
Deciduous shrub with multi-stem base
Full-crowned deciduous shrub
Large deciduous canopy tree
2 SECTION 2 THROUGH NORTHERN LANDSCAPE
Scale: 1:100
This section shows the northern landscape buffer, featuring deciduous trees and shrubs screening a private patio area.
- Private patio
Building section profile showing windows and recessed balconies
Multi-stemmed deciduous tree or large shrub
Broad deciduous tree with dense green leaves
Tall, upright green shrubbery
3 SECTION 3 TROUGH BURNSIDE STREETSCAPE
Scale: 1:100
This section depicts the public realm along Burnside Road, integrating pedestrian and cycling paths with a rain garden.
- Private patio
- Rain garden
- Sidewalk
- Bike lane
- Burnside Road
Building section profile with ground floor and upper residential levels
Deciduous tree with light green foliage
Mature deciduous tree with a rounded crown
Deciduous shrub with multi-stem base
4 SECTION 4 THROUGH PEDESTRIAN PATH
Scale: 1:100
This section cuts through the pedestrian path, showing its proximity to private patios and significant conifer plantings.
- Pedestrian path
- Private patio
5 SECTION 5 THROUGH HELMCKEN ROAD
Scale: 1:100
This section shows the interface between the building and Helmcken Road, including a bike lane, sidewalk, and ornamental grass plantings.
- Helmcken Road
- Bike lane
- Sidewalk
- Private patio
KEY PLAN
Scale: 1:1000
The key plan shows the building footprint and site layout, with numbered callouts (1 through 5) indicating the location and direction of each landscape section.
