Appendix
Eagles Nest Residences Site Plan
March 10, 2020Page 3561 section
Architectural site plan showing building locations (3 to 6 storeys), property lines, and landscape preservation areas.
dHKarchitectsBuildings ranging from 3 to 6 storeysWoonerf and Community Green spaces
Eagles Nest Residences - Site Plan
Project Details
- Project Name: Eagles Nest Residences
- Location: Helmcken Rd, View Royal BC
- Drawing Title: Site Plan
- Drawing Number: A101
- Project Number: 1827
- Date: 22 JAN 2020
- Scale: 1:250
- Drawn By: EDS
- Checked By: RAW
Revision History
| Rev | Date | Description |
|---|---|---|
| - | 17 SEP 2018 | ISSUED FOR REZONING |
| 1 | 28 JUN 2019 | RE-ISSUED FOR REZONING |
| 1 | 22 JAN 2020 | RE-ISSUED FOR REZONING |
Plan Components and Labels
- Building Heights:
- 6 STOREYS
- 5 STOREYS
- 4 STOREYS
- 4 STOREYS (WITH PARTIAL 5TH FLOOR)
- 3 STOREYS
- Site Features:
- COMMUNITY GREEN
- WOONERF
- FEATURE RAIN GARDEN
- PRESERVED TREES AND LANDSCAPE
- PRESERVED ROCK OUTCROP
- PROPERTY LINE
- Surrounding Roads:
- BURNSIDE ROAD
- HELMCKEN ROAD
- Note: All dimensions are shown in millimeters.
- Diagrams: North arrow and solar orientation (June/December) diagram.
Office Information
- Victoria Office: 977 Fort Street, Victoria BC V8V 3K3 | T 1 • 250 • 658 • 3367
- Nanaimo Office: 102 - 5190 Dublin Way, Nanaimo BC V9T 0H2 | T 1 • 250 • 585 • 5810
Page 356
