Appendix B: Roadway Modifications Concept Plans
Engineering concept plans for laning upgrades, including a second westbound through lane and pedestrian refuge, and a northbound left-turn lane.
Eagle Nest Helmcken Road Report
APPENDIX B: ROADWAY MODIFICATIONS CONCEPT PLANS
2ND WB THRU LANE W/ PED REFUGE HELMCKEN RD / WATKISS WAY
EAGLE NEST TIA
CONCEPT DESIGN ONLY - NOT FOR CONSTRUCTION
Project Information
| Field | Value |
|---|---|
| Designed | TV |
| Drawn | TV |
| Project No. | 2497.B01 |
| Date | MAR 12, 2019 |
| Scale | 1:750 |
These Design Documents are prepared solely for the use by the party with whom the Design Professional has entered into a contract, and there are no representations of any kind made by the Design Professional to any party with whom the Design Professional has not entered into contract.
BURNSIDE RD NB LT LANE BURNSIDE RD / HELMCKEN RD
EAGLE NEST TIA
CONCEPT DESIGN ONLY - NOT FOR CONSTRUCTION
Project Information
| Field | Value |
|---|---|
| Designed | TV |
| Drawn | TV |
| Project No. | 2497.B01 |
| Drawing No. | S-2 |
| Date | NOV 15, 2018 |
| Revision | 0 |
| Scale | 1:500 |
These Design Documents are prepared solely for the use by the party with whom the Design Professional has entered into a contract, and there are no representations of any kind made by the Design Professional to any party with whom the Design Professional has not entered into contract.
