Appendix
Appendix C: Dedicated Right Turn Lane Concept Plan
March 10, 2020Pages 480–4811 section
A concept plan showing a proposed second westbound through lane and a dedicated right-turn lane at the Helmcken Rd and Watkiss Way intersection.
Date: December 21, 2018Project No: 2497.B01
Eagle Nest Helmcken Road Report
APPENDIX C: DEDICATED RIGHT TURN LANE CONCEPT PLAN
2ND WB THRU LANE & RIGHT LANE HELMCKEN RD / WATKISS WAY EAGLE NEST TIA
These Design Documents are prepared solely for the use by the party with whom the Design Professional has entered into a contract, and there are no representations of any kind made by the Design Professional to any party with whom the Design Professional has not entered into contract.
| Field | Detail |
|---|---|
| DESIGNED: | MJO |
| DRAWN: | MJO |
| PROJECT NO: | 2497.B01 |
| DRAWING NO: | S-2 |
| DATE: | DEC 21-2018 |
| REVISION: | 0 |
| SCALE: | 1:1,000 |
#501, 740 - Hillside Ave Victoria, BC V8B TZ4 T. 250.388.9877 F. 250.388.9879 www.wattconsultinggroup.com
Page 480–481
