Attachment 3: Erskine Multifamily Proposed Materials (PR7)
Architectural material board for the 9 Erskine Lane development detailing cladding, roofing, and trim specifications.
ERSKINE MULTIFAMILY
PROPOSED MATERIALS
FIBRE CEMENT PANELS "IRON GREY" SMOOTH FINISH
WINDOW BOXES: FIBRE CEMENT LAP "CEDARTONE"
FIBRE CEMENT PANELS "GREY SLATE" SMOOTH FINISH
FIBRE CEMENT PANELS "LIGHT MIST" SMOOTH FINISH
ASPHALT SHINGLE ROOFING "CHARCOAL GREY"
HANDRAILS + FASCIAS PAINTED "BLACK"
Notes CONTRACTOR TO VERIFY ALL LINES, LEVELS, SURVEYS, DIMENSIONS, LOCATION OF BUILDING ON SITE AND LOCATION OF ALL SERVICES PRIOR TO CONSTRUCTION. ALL WORK TO BE DONE IN ACCORDANCE WITH THE B.C. BUILDING CODE, CURRENT EDITION AND ALL LOCAL BUILDING BYLAWS.
COPYRIGHT RESERVED. THESE PLANS ARE THE PROPERTY OF THUJA ARCHITECTURE STUDIO TO BE USED SOLELY FOR THE PROJECT SHOWN. UNAUTHORIZED REPRODUCTION OR USE IN ANY MANNER IS NOT PERMISSIBLE.
Architect Information Tonis Schulte Architect AIBC LEED AP 41289 Horizon Dr. Squamish BC V8B 0T7 T: 250.650.7901 E: info@thujaarchitecture.ca
Revisions
| NO. | DATE |
|---|---|
| ISSUED FOR REVIEW | JUL 07 2019 |
| ISSUED FOR REVIEW | AUG 13 2019 |
| ISSUED FOR REVIEW | OCT 23 2019 |
| ISSUED FOR REZONE | NOV 04 2019 |
| ISSUED FOR REZONE | JAN 23 2020 |
Project Details
- PROJECT: ERSKINE MULTIFAMILY
- DRAWING: PROPOSED MATERIALS
- SCALE: AS NOTED
- PROJECT NO: 20--
- DATE:
- DRAWN BY: TS/SW
- SHEET: PR7
