Committee of the Whole/Documents/Attachment 3: Erskine Multifamily Proposed Renderings (PR8)
Appendix

Attachment 3: Erskine Multifamily Proposed Renderings (PR8)

March 10, 2020Page 5311 section

Visual renderings of the overall development site and the five-storey residential building proposed for the lot.

9.2.3 b) Rezoning Application No. 2020/02 - 9 Erskine Lane
9 Erskine LaneFive-storey building lotOverall site view renderings

ERSKINE MULTIFAMILY

PROPOSED RENDERINGS

OVERALL VIEW

Architectural rendering showing an overall view of multiple apartment buildings within the Erskine Multifamily development.
Architectural rendering showing an overall view of multiple apartment buildings within the Erskine Multifamily development.

FIVE STOREY LOT

Detailed architectural rendering of the five-storey buildings in the development, featuring balconies and landscaped surroundings.
Detailed architectural rendering of the five-storey buildings in the development, featuring balconies and landscaped surroundings.

Project Information

  • Architect: THUJA architecture + design

Issue History

Description Date
ISSUED FOR REVIEW JUL 07 2019
ISSUED FOR REVIEW AUG 13 2019
ISSUED FOR REVIEW OCT 23 2019
ISSUED FOR REZONE NOV 04 2019
ISSUED FOR REZONE JAN 23 2020
  • Project: ERSKINE MULTIFAMILY
  • Drawing: PROPOSED RENDERINGS
  • Scale: AS NOTED
  • Project No: 20--
  • Drawn By: TS/SW
  • Sheet: PR8
Page 531
Extracted from: 2020 03 10 Committee of the Whole Agenda - Agenda - Pdf
