APPENDIX C OFFSITE SANITARY SEWER - FIGURE 3 AND SANITARY SEWER CAPACITY ASSESSMENT
March 10, 2020Pages 630–6334 sections
Assessment of the offsite sanitary sewer system's capacity to handle the projected flow from the new development.
9 Erskine LaneOctober 31, 2019G:\My Drive\Civil\Civil Projects\2253 - 9 Erskine Lane
APPENDIX C
OFFSITE SANITARY SEWER - FIGURE 3 AND SANITARY SEWER CAPACITY ASSESSMENT
Page 630–633
9 ERSKINE LANE OFFSITE SANITARY SEWER - FIGURE 3
TOWN OF VIEW ROYAL
CIVIC ADDRESS: 9 ERSKINE LANE, LOT B, TOWN OF VIEW ROYAL, PLAN VIP26648
OCTOBER 2, 2019 FOR DISCUSSION PURPOSES ONLY
IEL PROJECT - 2253 ISSUED: OCT 09, 2019 DRAWN BY: KK CHECKED BY: MJA
[Plan view map showing the offsite sanitary sewer route from 9 Erskine Lane. The route begins at the development site with Buildings A (79 units), B (79 units), C (107 units), and D (107 units) on Erskine Lane near Watkiss Way. The sewer line travels along Erskine Lane and the Galloping Goose Trail, crosses the Trans Canada Highway, continues through Vickery Road and Viewcrest Drive, and ultimately connects to the Helmcken Park Pump Station near Craigflower Creek.]
Page 630–633
TABLE 1 - SANITARY SYSTEM EXISTING CAPACITY ASSESSMENT
| PROJECT: | 9 Erskine Lane | DATE: | 10/31/2019 |
|---|---|---|---|
| JOB No. | 2253 | ENG.: | MJA |
| FILE: | G:\My Drive\Civil\Civil Projects\2253 - 9 Erskine Lane\9 Calculations & Estimates\9.3 Design Spreadsheet Information[2253- Table 1 - Existing System Assessment - Oct 29 2019.xlsx]A | DESIGN: | RBJ |
| SINGLE-FAMILY CAPITA | 2.75 Per Unit | CHECKED: | |
| MULTI-FAMILY (HIGH) CAPITA | 1.85 Per Unit | ||
| RESIDENTIAL FLOW | 213 L/Capita/Day | ||
| INFILTRATION | 32500 L/ha/Day (100 yr) | ||
| PEAKING FACTOR | Harmon Formula | ||
| REFERENCE: | View Royal Sanitary Master Plan January 2019 | ||
| BASED ON: | 0.67 x SFC |
FIGURES GIVEN BELOW APPLY TO THE LOWER END OF EACH LINE
| LINE | LENGTH (m) | SLOPE (%) | Single-Family Units (Incr.) | Single-Family Units (Sum) | Multi-Family Units (Incr.) | Multi-Family Units (Sum) | Catchment (ha) (Area) | Catchment (ha) (Sum) | Total Capita | Infiltration (L/s) | Average DWF (L/s) | Peaking Factor | Peak DWF (L/s) | Existing Commercial Flow (L/s) | Proposed Commercial Flow (L/s) | Total Flow Qa (L/s) | Total Flow Qa (m³/s) | PIPE SIZE Ø (mm) | SLOPE (%) | n | Qf (m³/s) | Vf (m/s) | Tf (min) | Qa/Qf | d/D (chart) | Va/Vf (chart) | Va |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NewSMH 1 - SMH 2 | 35.00 | @ 2.00 % | 0.00 | 0.00 | 0.00 | 0.00 | 0.86 | 0.86 | 0.00 | 0.323 | 0.000 | 4.500 | 0.000 | 0.000 | 0.000 | 0.32 | 0.00032 | 200 | @ 2.00 % | 0.013 | 0.046 | 1.48 | 0.40 | 0.0070 | 0.13 | 0.48 | 0.71 |
| SMH 2 - SCO531 | 51.60 | @ 6.00 % | 0.00 | 0.00 | 0.00 | 0.00 | 0.00 | 0.86 | 0.00 | 0.000 | 0.000 | 4.500 | 0.000 | 0.000 | 0.000 | 0.32 | 0.00032 | 200 | @ 6.00 % | 0.013 | 0.080 | 2.56 | 0.34 | 0.0040 | 0.18 | 0.60 | 1.53 |
| SCO531-SMH530 | 62.00 | @ 14.40 % | 3.00 | 3.00 | 0.00 | 0.00 | 0.17 | 1.03 | 8.25 | 0.064 | 0.020 | 4.422 | 0.090 | 0.000 | 0.000 | 0.48 | 0.00048 | 200 | @ 14.40 % | 0.013 | 0.124 | 3.96 | 0.26 | 0.0038 | 0.24 | 0.68 | 2.69 |
| SMH530-SMH529 | 31.00 | @ 1.73 % | 0.00 | 3.00 | 65.00 | 65.00 | 2.13 | 3.16 | 120.25 | 0.801 | 0.296 | 4.221 | 1.251 | 0.000 | 0.000 | 2.53 | 0.00253 | 200 | @ 1.73 % | 0.013 | 0.043 | 1.37 | 0.38 | 0.0586 | 0.13 | 0.48 | 0.66 |
| New Service-SMH529 | 10.00 | @ 2.00 % | 0.00 | 3.00 | 0.00 | 65.00 | 1.60 | 4.76 | 0.00 | 0.602 | 0.000 | 4.500 | 0.000 | 0.000 | 0.000 | 3.13 | 0.00313 | 200 | @ 2.00 % | 0.013 | 0.046 | 1.48 | 0.11 | 0.0675 | 0.13 | 0.48 | 0.71 |
| SMH529-SMH528 | 48.00 | @ 1.90 % | 2.00 | 5.00 | 0.00 | 65.00 | 0.53 | 5.29 | 5.50 | 0.199 | 0.014 | 4.436 | 0.060 | 0.000 | 0.000 | 3.39 | 0.00339 | 200 | @ 1.90 % | 0.013 | 0.045 | 1.44 | 0.56 | 0.0750 | 0.13 | 0.48 | 0.69 |
| SMH528-SMH527 | 88.00 | @ 2.86 % | 0.00 | 5.00 | 70.00 | 135.00 | 0.53 | 5.82 | 129.50 | 0.199 | 0.319 | 4.211 | 1.344 | 0.000 | 0.000 | 4.93 | 0.00493 | 200 | @ 2.86 % | 0.013 | 0.055 | 1.77 | 0.83 | 0.0890 | 0.15 | 0.54 | 0.95 |
| SMH527-SMH67A | 49.00 | @ 2.78 % | 0.00 | 5.00 | 0.00 | 135.00 | 0.00 | 5.82 | 0.00 | 0.000 | 0.000 | 4.500 | 0.000 | 0.000 | 0.000 | 4.93 | 0.00493 | 200 | @ 2.78 % | 0.013 | 0.055 | 1.74 | 0.47 | 0.0902 | 0.15 | 0.54 | 0.94 |
| SMH67A-SMH67 | 40.00 | @ 3.54 % | 7.00 | 12.00 | 0.00 | 135.00 | 0.00 | 5.82 | 19.25 | 0.000 | 0.047 | 4.383 | 0.208 | 0.000 | 0.000 | 5.14 | 0.00514 | 200 | @ 3.54 % | 0.013 | 0.062 | 1.96 | 0.34 | 0.0833 | 0.16 | 0.58 | 1.14 |
| SMH67-SMH66 | 40.00 | @ 3.58 % | 2.00 | 14.00 | 0.00 | 135.00 | 0.17 | 5.99 | 5.50 | 0.064 | 0.014 | 4.436 | 0.060 | 0.000 | 0.000 | 5.27 | 0.00527 | 200 | @ 3.58 % | 0.013 | 0.062 | 1.98 | 0.34 | 0.0849 | 0.16 | 0.58 | 1.15 |
| SMH66-SMH65A | 26.50 | @ 0.92 % | 2.00 | 16.00 | 0.00 | 135.00 | 0.17 | 6.16 | 5.50 | 0.064 | 0.014 | 4.436 | 0.060 | 0.000 | 0.000 | 5.39 | 0.00539 | 200 | @ 0.92 % | 0.013 | 0.031 | 1.00 | 0.44 | 0.1714 | 0.12 | 0.43 | 0.43 |
| SMH65A-SMH65 | 100.60 | @ 0.92 % | 5.00 | 21.00 | 0.00 | 135.00 | 0.51 | 6.67 | 13.75 | 0.192 | 0.034 | 4.400 | 0.149 | 0.000 | 0.000 | 5.73 | 0.00573 | 200 | @ 0.92 % | 0.013 | 0.031 | 1.00 | 1.67 | 0.1822 | 0.12 | 0.43 | 0.43 |
| SMH65-SMH64 | 94.40 | @ 1.04 % | 4.00 | 25.00 | 0.00 | 135.00 | 0.41 | 7.08 | 11.00 | 0.154 | 0.027 | 4.411 | 0.120 | 0.000 | 0.000 | 6.01 | 0.00601 | 200 | @ 1.04 % | 0.013 | 0.033 | 1.06 | 1.48 | 0.1796 | 0.12 | 0.43 | 0.46 |
| Southwest to SMH 64 | 315.00 | @ 3.80 % | 44.00 | 69.00 | 0.00 | 135.00 | 3.94 | 11.02 | 121.00 | 1.482 | 0.298 | 4.220 | 1.259 | 0.000 | 0.000 | 8.75 | 0.00875 | 200 | @ 3.80 % | 0.013 | 0.064 | 2.04 | 2.58 | 0.1368 | 0.16 | 0.58 | 1.18 |
| SMH64-SMH63 | 23.00 | @ 1.74 % | 0.00 | 69.00 | 0.00 | 135.00 | 0.29 | 11.31 | 0.00 | 0.109 | 0.000 | 4.500 | 0.000 | 0.000 | 0.000 | 8.86 | 0.00886 | 200 | @ 1.74 % | 0.013 | 0.043 | 1.38 | 0.28 | 0.2047 | 0.13 | 0.48 | 0.66 |
| Southeast to SMH 63 | 315.00 | @ 3.80 % | 37.00 | 106.00 | 0.00 | 135.00 | 4.19 | 15.50 | 101.75 | 1.576 | 0.251 | 4.242 | 1.064 | 0.000 | 0.000 | 11.39 | 0.01139 | 200 | @ 3.80 % | 0.013 | 0.064 | 2.04 | 2.58 | 0.1781 | 0.16 | 0.58 | 1.18 |
| Existing from North to P.S. | 1000.00 | @ 2.00 % | 215.00 | 321.00 | 21.00 | 156.00 | 27.00 | 42.50 | 630.10 | 10.156 | 1.553 | 3.920 | 6.090 | 0.000 | 0.000 | 25.10 | 0.02510 | 200 | @ 2.00 % | 0.013 | 0.046 | 1.48 | 11.29 | 0.5412 | 0.13 | 0.48 | 0.71 |
Page 630–633
TABLE 2 - SANITARY SYSTEM PROPOSED CAPACITY ASSESSMENT
| PROJECT: | 9 Erskine Lane | DATE: | 10/31/2019 |
|---|---|---|---|
| JOB No. | 2253 | ENG.: | MJA |
| FILE: | G:\My Drive\Civil\Civil Projects\2253 - 9 Erskine Lane\9 Calculations & Estimates\9.3 Design Spreadsheet Information[2253- Table 1 - Proposed System Assessment - Oct 29 2019.xlsx]A | DESIGN: | RBJ |
| SINGLE-FAMILY CAPITA | 2.75 Per Unit | CHECKED: | |
| MULTI-FAMILY (HIGH) CAPITA | 1.85 Per Unit | ||
| RESIDENTIAL FLOW | 213 L/Capita/Day | ||
| INFILTRATION | 32500 L/ha/Day (100 yr) | ||
| PEAKING FACTOR | Harmon Formula | ||
| REFERENCE: | View Royal Sanitary Master Plan January 2019 | ||
| BASED ON: | 0.67 x SFC |
FIGURES GIVEN BELOW APPLY TO THE LOWER END OF EACH LINE
| LINE | LENGTH (m) | SLOPE (%) | Single-Family Units (Incr.) | Single-Family Units (Sum) | Multi-Family Units (Incr.) | Multi-Family Units (Sum) | Catchment (ha) (Area) | Catchment (ha) (Sum) | Total Capita | Infiltration (L/s) | Average DWF (L/s) | Peaking Factor | Peak DWF (L/s) | Existing Commercial Flow (L/s) | Proposed Commercial Flow (L/s) | Total Flow Qa (L/s) | Total Flow Qa (m³/s) | PIPE SIZE Ø (mm) | SLOPE (%) | n | Qf (m³/s) | Vf (m/s) | Tf (min) | Qa/Qf | d/D (chart) | Va/Vf (chart) | Va |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NewSMH 1 - SMH 2 | 35.00 | @ 2.00 % | 0.00 | 0.00 | 158.00 | 158.00 | 0.86 | 0.86 | 292.30 | 0.323 | 0.721 | 4.083 | 2.942 | 0.000 | 0.000 | 3.27 | 0.00327 | 200 | @ 2.00 % | 0.013 | 0.046 | 1.48 | 0.40 | 0.0704 | 0.13 | 0.48 | 0.71 |
| SMH 2 - SCO531 | 51.60 | @ 6.00 % | 0.00 | 0.00 | 0.00 | 158.00 | 0.00 | 0.86 | 0.00 | 0.000 | 0.000 | 4.500 | 0.000 | 0.000 | 0.000 | 3.27 | 0.00327 | 200 | @ 6.00 % | 0.013 | 0.080 | 2.56 | 0.34 | 0.0407 | 0.18 | 0.60 | 1.53 |
| SCO531-SMH530 | 62.00 | @ 14.40 % | 3.00 | 3.00 | 0.00 | 158.00 | 0.17 | 1.03 | 8.25 | 0.064 | 0.020 | 4.422 | 0.090 | 0.000 | 0.000 | 3.42 | 0.00342 | 200 | @ 14.40 % | 0.013 | 0.124 | 3.96 | 0.26 | 0.0275 | 0.24 | 0.68 | 2.69 |
| SMH530-SMH529 | 31.00 | @ 1.73 % | 0.00 | 3.00 | 65.00 | 223.00 | 2.13 | 3.16 | 120.25 | 0.801 | 0.296 | 4.221 | 1.251 | 0.000 | 0.000 | 5.47 | 0.00547 | 200 | @ 1.73 % | 0.013 | 0.043 | 1.37 | 0.38 | 0.1268 | 0.13 | 0.48 | 0.66 |
| New Service-SMH529 | 10.00 | @ 2.00 % | 0.00 | 3.00 | 214.00 | 437.00 | 1.60 | 4.76 | 395.90 | 0.602 | 0.976 | 4.024 | 3.928 | 0.000 | 0.000 | 10.00 | 0.01000 | 200 | @ 2.00 % | 0.013 | 0.046 | 1.48 | 0.11 | 0.2156 | 0.13 | 0.48 | 0.71 |
| SMH529-SMH528 | 48.00 | @ 1.90 % | 2.00 | 5.00 | 0.00 | 437.00 | 0.53 | 5.29 | 5.50 | 0.199 | 0.014 | 4.436 | 0.060 | 0.000 | 0.000 | 10.26 | 0.01026 | 200 | @ 1.90 % | 0.013 | 0.045 | 1.44 | 0.56 | 0.2270 | 0.13 | 0.48 | 0.69 |
| SMH528-SMH527 | 88.00 | @ 2.86 % | 0.00 | 5.00 | 70.00 | 507.00 | 0.53 | 5.82 | 129.50 | 0.199 | 0.319 | 4.211 | 1.344 | 0.000 | 0.000 | 11.81 | 0.01181 | 200 | @ 2.86 % | 0.013 | 0.055 | 1.77 | 0.83 | 0.2128 | 0.15 | 0.54 | 0.95 |
| SMH527-SMH67A | 49.00 | @ 2.78 % | 0.00 | 5.00 | 0.00 | 507.00 | 0.00 | 5.82 | 0.00 | 0.000 | 0.000 | 4.500 | 0.000 | 0.000 | 0.000 | 11.81 | 0.01181 | 200 | @ 2.78 % | 0.013 | 0.055 | 1.74 | 0.47 | 0.2159 | 0.15 | 0.54 | 0.94 |
| SMH67A-SMH67 | 40.00 | @ 3.54 % | 7.00 | 12.00 | 0.00 | 507.00 | 0.00 | 5.82 | 19.25 | 0.000 | 0.047 | 4.383 | 0.208 | 0.000 | 0.000 | 12.01 | 0.01201 | 200 | @ 3.54 % | 0.013 | 0.062 | 1.96 | 0.34 | 0.1947 | 0.16 | 0.58 | 1.14 |
| SMH67-SMH66 | 40.00 | @ 3.58 % | 2.00 | 14.00 | 0.00 | 507.00 | 0.17 | 5.99 | 5.50 | 0.064 | 0.014 | 4.436 | 0.060 | 0.000 | 0.000 | 12.14 | 0.01214 | 200 | @ 3.58 % | 0.013 | 0.062 | 1.98 | 0.34 | 0.1956 | 0.16 | 0.58 | 1.15 |
| SMH66-SMH65A | 26.50 | @ 0.92 % | 2.00 | 16.00 | 0.00 | 507.00 | 0.17 | 6.16 | 5.50 | 0.064 | 0.014 | 4.436 | 0.060 | 0.000 | 0.000 | 12.26 | 0.01226 | 200 | @ 0.92 % | 0.013 | 0.031 | 1.00 | 0.44 | 0.3898 | 0.12 | 0.43 | 0.43 |
| SMH65A-SMH65 | 100.60 | @ 0.92 % | 5.00 | 21.00 | 0.00 | 507.00 | 0.51 | 6.67 | 13.75 | 0.192 | 0.034 | 4.400 | 0.149 | 0.000 | 0.000 | 12.60 | 0.01260 | 200 | @ 0.92 % | 0.013 | 0.031 | 1.00 | 1.67 | 0.4006 | 0.12 | 0.43 | 0.43 |
| SMH65-SMH64 | 94.40 | @ 1.04 % | 4.00 | 25.00 | 0.00 | 507.00 | 0.41 | 7.08 | 11.00 | 0.154 | 0.027 | 4.411 | 0.120 | 0.000 | 0.000 | 12.88 | 0.01288 | 200 | @ 1.04 % | 0.013 | 0.033 | 1.06 | 1.48 | 0.3850 | 0.12 | 0.43 | 0.46 |
| Southwest to SMH 64 | 315.00 | @ 3.80 % | 44.00 | 69.00 | 0.00 | 507.00 | 3.94 | 11.02 | 121.00 | 1.482 | 0.298 | 4.220 | 1.259 | 0.000 | 0.000 | 15.62 | 0.01562 | 200 | @ 3.80 % | 0.013 | 0.064 | 2.04 | 2.58 | 0.2443 | 0.16 | 0.58 | 1.18 |
| SMH64-SMH63 | 23.00 | @ 1.74 % | 0.00 | 69.00 | 0.00 | 507.00 | 0.29 | 11.31 | 0.00 | 0.109 | 0.000 | 4.500 | 0.000 | 0.000 | 0.000 | 15.73 | 0.01573 | 200 | @ 1.74 % | 0.013 | 0.043 | 1.38 | 0.28 | 0.3635 | 0.13 | 0.48 | 0.66 |
| Southeast to SMH 63 | 315.00 | @ 3.80 % | 37.00 | 106.00 | 0.00 | 507.00 | 4.19 | 15.50 | 101.75 | 1.576 | 0.251 | 4.242 | 1.064 | 0.000 | 0.000 | 18.26 | 0.01826 | 200 | @ 3.80 % | 0.013 | 0.064 | 2.04 | 2.58 | 0.2856 | 0.16 | 0.58 | 1.18 |
| Existing from North to P.S. | 1000.00 | @ 2.00 % | 215.00 | 321.00 | 21.00 | 528.00 | 27.00 | 42.50 | 630.10 | 10.156 | 1.553 | 3.920 | 6.090 | 0.000 | 0.000 | 31.97 | 0.03197 | 200 | @ 2.00 % | 0.013 | 0.046 | 1.48 | 11.29 | 0.6893 | 0.13 | 0.48 | 0.71 |
