APPENDIX D STORMWATER MANAGEMENT - FIGURE 4
March 10, 2020Pages 634–6354 sections
Stormwater management site plan illustrating drainage catchments and proposed management areas.
9 Erskine LaneOctober 2, 20190.8586 ha North catchment area1.4927 ha South catchment area
APPENDIX D
Page 634–635
STORMWATER MANAGEMENT - FIGURE 4
Page 634–635
9 ERSKINE LANE
Page 634–635
STORMWATER MANAGEMENT - FIGURE 4
TOWN OF VIEW ROYAL
CIVIC ADDRESS: 9 ERSKINE LANE, LOT B, TOWN OF VIEW ROYAL, PLAN VIP26648
LEGEND
- ON-SITE CATCHMENT AREA
- NORTH — 0.8586 ha
- SOUTH — 1.4927 ha
- EXISTING FLOW DIRECTION
- PROPOSED FLOW DIRECTION
OCTOBER 2, 2019 FOR DISCUSSION PURPOSES ONLY
| IEL PROJECT - 2253 | ISSUED: OCT 09, 2019 |
| DRAWN BY: KK | CHECKED BY: MJA |
Map Features and Annotations:
- Stoneridge Wetland Park located to the northwest.
- Watkiss Way runs along the western boundary.
- Erskine Lane runs through the center of the site.
- Galloping Goose Trail and Trans Canada Highway are located to the south and southeast.
- Craigflower Creek is located to the southeast.
- Buildings identified:
- BLDG A (79 UNITS)
- BLDG B (79 UNITS)
- BLDG C (107 UNITS)
- BLDG D (107 UNITS)
- Stormwater Management:
- Proposed Rainwater Management Areas identified near Buildings B, C, and south of Erskine Lane.
- Mix of open ditch and culverts leading to the creek.
- Existing and proposed flow directions indicate drainage towards Craigflower Creek.
- 900Ø CSP (Corrugated Steel Pipe) noted in two locations.
- Scale: 1:1250 (0 to 75m scale bar provided).
