Committee of the Whole/Documents/Attachment 4 - 231 Heddle Ave. Cover Sheet & Context Plan
Appendix

Attachment 4 - 231 Heddle Ave. Cover Sheet & Context Plan

March 13, 2018Page 615 sections

Architectural cover sheet showing project data and contextual site plan.

2. APPROVAL OF AGENDA
Site Area: 0.45 haTotal Floor Area (GFA): 1,144 m²Site Coverage: 21%

231 HEDDLE AVE.

Architectural rendering titled "VIEW FROM DRIVEWAY AT HEDDLE"
Architectural rendering titled "VIEW FROM DRIVEWAY AT HEDDLE"
Page 61

CONTEXT PLAN

Context plan aerial view indicating the development site and surrounding context with designated 3D view angles
Context plan aerial view indicating the development site and surrounding context with designated 3D view angles
Page 61

SITE PLAN W. ADJACENT HOUSES

SCALE = 1:400

Detailed site plan showing building footprints for Buildings 1, 2, and 3, and adjacent properties
Detailed site plan showing building footprints for Buildings 1, 2, and 3, and adjacent properties
Page 61

PROPOSED PROJECT INFORMATION

Summary table of proposed project specifications and the drawing list
Summary table of proposed project specifications and the drawing list
Category Details
CIVIC ADDRESS 231 HEDDLE AVENUE
LEGAL ADDRESS LOT 3, SECTION 8, ESQUIMALT DISTRICT PLAN 45599
EXISTING ZONING R-1 (LARGE LOT)
REZONE TO RT-1 (ATTACHED RESIDENTIAL)
SITE AREA 0.415 Ha / 4,500 m² / 48,438 ft²
BUILDING AREA 930 m² / 10,010 ft²
SITE COVERAGE 21%
TOTAL IMPERVIOUS SURFACE AREA 1,364.1 m² / 14,680 ft²
TOTAL FLOOR SPACE (GFA) 1,888.9 m² / 20,332 ft²
FLOOR AREA RATIO 0.42 : 1 (MAX. 0.5)
SETBACKS FRONT: 5.0m (16.4')
REAR: 4.5m (14.8')
SIDE: 4.5m (14.8')
NO. UNITS 9 TOWNHOUSES (2 STOREYS + BASEMENT)
UNIT AREA 214.4 m² / 2,308 ft² (END UNITS - QTY 6)
211.4 m² / 2,275 ft² (MIDDLE UNITS - QTY 3)
HEIGHT (FROM AVG. GRADE) BLDG 1 = 8.6m / 28' - 3"
BLDG 2 = 7.67 m / 25' - 2"
BLDG 3 = 9.71 m / 31' - 10"
PARKING REQUIRED 1.5 / UNIT (PER TABLE 5.2 - ROWHOUSE OR TOWNHOUSE): 14 UNIT TOTAL
PARKING PROVIDED 2 / UNIT: 18 UNIT TOTAL
Page 61

DRAWING LIST

  • A00 COVER SHEET / PROJECT INFO
  • A01 SITE PLAN
  • A02 BUILDING 1 - PLANS
  • A03 BUILDING 2 + 3 - PLANS
  • A04 BUILDING 1 - ELEVATIONS
  • A05 BUILDING 2 + 3 - ELEVATIONS
  • A06 SITE SECTIONS
  • A07 AERIAL VIEWS
  • A08 STREET VIEWS
  • L1 LANDSCAPE PLAN
  • SURV SURVEY

231 HEDDLE AVE. VICTORIA BC PROJECT NO. 17-020

Identification block for the project address and number
Identification block for the project address and number

COVER SHEET 2018.01.12 - REZONING APPLICATION

A00

Page 61
