231 HEDDLE AVE. PROPOSED LANDSCAPE PLAN, VICTORIA

Top section of the landscape plan including "Rain Gardens" informational graphic and existing Garry Oaks
Top section of the landscape plan including "Rain Gardens" informational graphic and existing Garry Oaks
Section of the landscape plan showing existing trees and "Suggested Ideas for Elevated Areas Built with Treated Fir"
Section of the landscape plan showing existing trees and "Suggested Ideas for Elevated Areas Built with Treated Fir"
Central section of the landscape plan showing residential building footprints and site layout
Central section of the landscape plan showing residential building footprints and site layout
Section of the landscape plan showing a permeable paver plaza and residential building footprints
Section of the landscape plan showing a permeable paver plaza and residential building footprints
Right section of the landscape plan showing examples of patio screening and a Garry Oak meadow area
Right section of the landscape plan showing examples of patio screening and a Garry Oak meadow area
Bottom right section of the landscape plan featuring the suggested native plant list and project information block
Bottom right section of the landscape plan featuring the suggested native plant list and project information block

Project Information

Client Scale Date Drawing No.
URBAN HABITATS 1:120 2018.01.17 2073 R

Site Plan Annotations

  • EXISTING GARRY OAKS
  • RAIN GARDEN
  • PERMEABLE PAVERS
  • EXISTING DOUGLAS FIR
  • EXISTING GRAND FIR
  • NATURALIZED PLANTING
  • EXISTING PACIFIC YEW
  • 4" x 4" TREATED FIR RETAINING WALL W/ SHRUBS & GRASSES (TYP.)
  • NATURALIZED AREA NATIVE ROCKERY PLANTS & GROUNDCOVERS
  • UTILITY POLE
  • PERMEABLE PAVER PLAZA
  • PAVED PLANTERS
  • NATURALIZED AREA TO BE RESTORED WITH NATIVE SPECIES TO BE RETAINED (INVASIVE SPECIES TO BE REMOVED)
  • PATIO SCREENING (TYPICAL)
  • SUGGESTED IDEAS FOR ELEVATED AREAS BUILT WITH TREATED FIR

SUGGESTED NATIVE PLANTS

TREE:

  • Acer Circinatum 'Pacific Fire' (red bark vine maple)

SHRUBS:

  • Cornus sericea (red osier dogwood)
  • Gaultheria shallon (salal)
  • Holodiscus discolor (oceanspray)
  • Mahonia aquifolium (Oregon grape)
  • Mahonia nervosa (cascade barberry)
  • Mahonia repens (creeping Oregon grape)
  • Oemleria cerasiformis (Indian plum)
  • Physocarpus capitatus (Pacific ninebark)
  • Ribes sanguineum (red-flowering currant)
  • Symphoricarpos albus (snowberry)

PERENNIAL GROUNDCOVERS/FERNS:

  • Blechnum spicant (deer fern)
  • Polypodium glycyrrhiza (licorice fern)
  • Vancouveria hexandra
