Site Plan + View Locator - 231 Heddle Ave

March 13, 2018Page 861 section

An architectural drawing showing the proposed site layout, building footprints, and neighborhood view perspectives for the Heddle Avenue development.

2. APPROVAL OF AGENDA
Project No: 17-020Date: 2017.11.20

SITE PLAN + VIEW LOCATOR

Project Information

  • Address: 231 HEDDLE AVE., VICTORIA BC
  • Project No: 17-020
  • Date: 2017.11.20 - NEIGHBOURHOOD MEETING
Detailed site plan and view locator for the residential development at 231 Heddle Avenue. The plan illustrates the layout of three buildings, parking areas, patios, property lines, and topographic details.
Detailed site plan and view locator for the residential development at 231 Heddle Avenue. The plan illustrates the layout of three buildings, parking areas, patios, property lines, and topographic details.

Site Plan Details

  • Buildings:
    • Building 1: Includes Unit Type A, Unit Type B (Mirrored), Unit Type C (Mirrored), and Unit Type D.
    • Building 2
    • Building 3: Includes Unit Type B, Unit Type C, and Unit Type D.
  • Site Features:
    • Designated parking areas.
    • Private patio areas for units.
    • Barrier fencing.
    • Retention of Garry Oak Meadow (note indicates invasive species to be removed).
    • 3D View markers (1, 2, and 3).
  • Surrounding Property Context:
    • Heddle Avenue (Road Plan EPP16862)
    • Lot 1 Plan 45669
    • Lot 2
    • Block 1 Plan 1688
    • Lot 5, Block 1, Plan 1688
    • Lot A Plan 45137
    • Lot 19
  • Scale: 1:200 (Site Plan)
Page 86
Extracted from: 2018 03 13 Committee of the Whole Agenda - Agenda - Pdf
