Appendix
Attachment 6: Site Plan – WSP, January 12, 2018
March 13, 2018Page 1111 section
A technical site plan showing the layout of the proposed handyDART office, maintenance building, bus wash, and parking areas.
Site Area: 48,254.71 sqmZoning: Proposed I-1 Light Industrial
BC TRANSIT - VIEW ROYAL
SITE PLAN
CIVIC ADDRESS: 2401 BURNSIDE ROAD WEST
LEGAL DESCRIPTION: THAT PART OF SECTION 1, ESQUIMALT LAND DISTRICT, LYING PARTLY ON PLAN 2200 AND PARTLY ON SUBDIVISION PLAN 8157 EXCEPT THAT PART ON PLAN VIP78054 PID 023-832-211
RESUBMISSION CONTACT: ARCHITECTURE 49 INC. SUITE 500 - 310 WEST BROADWAY VANCOUVER, BC V5Y 1R2 EMAIL: PARDEEP.SANDHU@ARCHITECTURE49.COM T: 604 736 9711
SITE INFORMATION
SITE ZONING: M1 LIGHT INDUSTRIAL
| CATEGORY | REQUIRED | PROPOSED |
|---|---|---|
| SETBACKS | ||
| Front Lot Line | 7.5m | 7.5m |
| Rear Lot Line | 7.5m | 7.5m |
| Side Lot Line | 4.5m | 11.2m |
| Flanking Lot Line | 6.0m | 1.3m |
| BUILDING HEIGHT | 12.0m | 10.2m |
| BUILDING WIDTH | — | 13.9m |
| ACCESSORY BUILDING HEIGHT | 4.5m | 4.3m |
SITE AREA: 40,314.71 sqm
BUILDING AREAS
| BUILDING / SECTION | AREA |
|---|---|
| BUS WASH | 120.30 sqm |
| FUEL STATION | 101.52 sqm |
| MAINT. ADMIN. BUILDING | 2,887.82 sqm |
| — OFFICE | 397.00 sqm |
| — MAINT. BAYS | 2,210.00 sqm |
| — STORES | 280.82 sqm |
| TOTAL | 3,109.64 sqm |
SITE COVERAGE AND DENSITY
| METRIC | CALCULATED VALUE | ALLOWED |
|---|---|---|
| FSR (3,109.64 / 40,314.71 = 0.08) | 0.08 | 0.75 ALLOWED |
| LOT COVERAGE (3,109.64 / 40,314.71 = 0.077) | 7.7% | 50% ALLOWED |
| IMPERMEABLE COVERAGE (12,580.00 / 40,314.71 = 0.312) | 31.2% | 60% ALLOWED |
Drawing No: VR-A1 Date: 2018-01-12 Scale: 1:500
Page 111
