Visual photo-simulations of the proposed facility as viewed from various vantage points on Burnside Road West and Watkiss Way.

2. APPROVAL OF AGENDA
Includes key plan showing five distinct view angles (A-E)

BC TRANSIT - VIEW ROYAL

STREET PERSPECTIVES

Drawing Number: VR-A0.1 Date: 2018-01-12 Scale: 1 : 1200 Architecture: 40

KEY PLAN showing site layout and viewpoint locations for Views A, B, C, D, and E
KEY PLAN showing site layout and viewpoint locations for Views A, B, C, D, and E
VIEW A street perspective rendering looking along a roadway
VIEW A street perspective rendering looking along a roadway

STREET PERSPECTIVES

Drawing Number: VR-A0.2 Date: 2018-01-12 Architecture: 40
