Attachment 3 - Site Plan and Elevations – Design Zone, Feb. 6, 2018 (Page 1 of 2)

Proposed Sport Court - 117 View Royal Ave.

Plan Number: 2285 Date: Feb. 6th-18 Drawn By: A. Mills Scale: 1/4" = 12" unless noted Page: One of 2

Site Plan

Scale: 1:250 The site plan shows the layout of the property at 117 View Royal Ave. and the adjacent neighbor.

• Existing Residence: Located on the property.
• Proposed Sport-Court: Positioned between the existing residence and the property line.
• Existing Neighb. Residence: Located to the west of the subject property.
• Property Line Dimensions:
  • North boundary: 29.30' / 8.93M and 51.90' / 15.82M
  • East boundary: 101.71' / 31.00M
  • South boundary: 75.03' / 22.87M
  • West boundary: Shared with neighboring property.
• Additional features: Patios, existing 10'-0" tall link fence, and rock retaining wall at the neighboring property line.

East Elevation

Direction: Looking West

• Features a 10'-0" top of proposed chain-link fencing.
• Includes a 3/8" wide chain-link gate.
• Shows concrete retaining walls and the sport-court slab relative to the finished grade.
• Notes an existing fence at the property line.

Cross Section

Direction: Looking East

• Total Height: 14'-0" (consisting of a 4'-0" concrete retaining wall and 10'-0" chain-link fence).
• Shows backfilled concrete retaining walls.
• Details the concrete sport court slab and chain-link fence/gate.
• Notes the finished grade level.

South Elevation

Direction: Looking North

• Shows the property line and the existing fence to remain.
• Displays the concrete sport-court slab and the chain-link fence relative to the finished grade.
