Committee of the Whole/Documents/Attachment 4 - Floor Plan – Design Zone, Feb. 6, 2018 (Page 2 of 2)
Appendix

Attachment 4 - Floor Plan – Design Zone, Feb. 6, 2018 (Page 2 of 2)

April 10, 2018Page 771 section

Floor plan for the proposed sport court area.

2. APPROVAL OF AGENDA
Feb. 6, 2018

FLOOR PLAN

Technical floor plan drawing for a proposed sport court at 117 View Royal Ave., showing dimensions, materials, and surrounding property features.
Technical floor plan drawing for a proposed sport court at 117 View Royal Ave., showing dimensions, materials, and surrounding property features.

Project Information

  • Plan No: 2285
  • Date: FEB. 5TH - 18
  • Scale: 1/4" = 12"
  • Drawn By: A. MILLS
  • Project: PROPOSED SPORT COURT
  • Address: 117 VIEW ROYAL AVE.

Drawing Notes and Annotations

  • Sport Court: 25' x 42' CONC. SLAB
  • Fencing and Walls:
    • 8" CONC. RETAINING WALLS
    • CHAIN-LINK FENCE ON CONC. RETAINING WALLS
    • CONC. RETAIN WALLS WITH CHAIN LINK FENCE ABOVE
    • CHAIN-LINK GATE
    • EXISTING 4' TO 8' TALL CONTINUOUS FENCE ON PROPERTY LINE TO REMAIN
  • Site Features:
    • LANDSCAPED AREAS
    • CONC. PATIO
    • EXISTING RESID. CONC. FOUNDATION WALLS
  • Dimensions:
    • Court Width: 25'-0"
    • Total Structure Width: 26'-4" (includes 8" walls)
    • Court Length: 42'-0"
    • Setback from existing foundation: 5'-0"
Page 77
