Site Plan A1.0 - Pawlak Residence

Site Plan - Pawlak Residence

Site plan drawing for 4 Governors Point Road, detailing the existing building, deck, patio, and proposed masonry wall construction relative to the high water mark setback.

Project Information

Project: Pawlak Residence
Address: 4 Governors Point Road, Town of View Royal, BC
Drawing Title: Site Plan
Sheet Number: A1.0
Scale: 1:150
Design / Drawn by: MBB

Plan Annotations

Structures: Existing Building, Existing Deck, and Existing Patio.
Existing Landscape: Existing Hedge and Existing Landscape Steps.
Site Features: Approximate location of the top of existing boulder wall.
Proposed Work: New masonry wall c/w 1070 high guard rail to be selected by owners, built on the toe of the existing boulder wall.
Setbacks: Approximate 15m setback from high water mark.

Revision History

No.	Date	Description
1	20070509	BUILDING PERMIT

Contact Information

Matthew Bergink
AutoCad Technician
Tel: 250.532.8548
Email: mbergink@gmail.com
