Elevation A2.0 - Pawlak Residence

May 8, 2018Page 1001 section

Vertical elevation drawing showing the ±2400mm height of the new masonry wall.

2 APPROVAL OF AGENDA
±2400 height masonry wall

Pawlak Residence

4 Governors Point Road Town of View Royal, BC

Elevation

Architectural elevation drawing of the Pawlak Residence showing a new masonry wall with a guard rail, existing house beyond, and landscape features including hedges and steps.
Architectural elevation drawing of the Pawlak Residence showing a new masonry wall with a guard rail, existing house beyond, and landscape features including hedges and steps.

Elevation Annotations:

  • EXISTING HEDGE
  • EXISTING HOUSE BEYOND
  • EXISTING LANDSCAPE STEPS
  • ±355
  • ±2400
  • NEW MASONRY WALL C/W 1070 HIGH GUARD RAIL TO BE SELECTED BY OWNERS
  • ±1448
  • EXISTING HEDGE
  • APPROXIMATE HEIGHT OF THE TOP OF EXISTING BOULDER WALL

Issue / Revisions

No. Date Description
1 2017/09/04 ISSUED FOR PERMIT

Project Information

  • Client: Pawlak Residence
  • Project: 4 Governors Point Road, Town of View Royal, BC
  • Drawing Title: Elevation
  • Design / Drawn by: MDB
  • Checked by: -
  • Scale: 1:100
  • Drawing No: A2.0
Page 100
