131 Presley Place Signage Illustrations

Report to Committee of the Whole

DP2017/09 – 131 Presley Pl Meeting January 16 2018

ATTACHMENTS:

Sign location and detail – Graphic FX Signs – undated
Proposed signage illustration – existing and proposed – Graphic FX Signs – undated

Attachment 1: Sign location and detail – Graphic FX Signs – undated

Close-up rendering of the building storefront at unit 2-131 under a beige awning

Close-up rendering of storefront units 3-131 and 4-131 under a beige awning with "For Lease" signage in windows

Aerial map of the development site at the corner of Six Mile Road and Presley Place, showing sign locations marked A, B, and C

Signage Specifications

Sign Types A & C: Lakeside Massage Therapy

Dimensions: 3.66 m x 1.22 m
Total Area: 4.45 m²
Letter Height: 10.75" (.27 m)

Sign Type B: TENANT

Dimensions: 3.66 m x 1.22 m
Total Area: 4.45 m²
Letter Height: Not to exceed 15" (.38 m)

General Construction Details:

4" Deep, LED illuminated, plexi push through aluminum sign box.
Painted customer approved colour.
Translucent vinyl applied to plexi.

Installation Details

Unit 2-131 (Sign B): Located on a 12m Tenant Frontage. The bottom of the sign is 3.4m (134") from grade.
Unit 3-131 (Sign A): Located on an 8.68m Tenant Frontage. The bottom of the sign is 3.63m (143") from grade.
Unit 4-131 (Sign C): Located on a 7.62m Tenant Frontage. The bottom of the sign is 3.63m (143") from grade.

Attachment 2: Proposed signage illustration – existing and proposed – Graphic FX Signs – undated

Existing

Photograph of the two-story wood-clad building at 131 Presley Place as it currently exists, featuring "URBAN GROUND MARKET" signage

Proposed Signage

The proposed signage plan illustrates the addition of three black rectangular sign boxes mounted on the building fascia above the ground-floor awning. From left to right, the rendering shows a "TENANT" sign (Sign B), a "Lakeside Massage Therapy" sign (Sign A), and a second "TENANT" sign (Sign C), replacing the vacant space on the facade while retaining the existing "URBAN GROUND MARKET" signage on the upper right portion of the building.
