Committee of the Whole/Documents/Attachment 4: Site Plan - 2427 Chilco Road
Appendix

Attachment 4: Site Plan - 2427 Chilco Road

January 16, 2018Page 831 section

Survey and site plan showing the exact siting of the proposed accessory structure on the property.

2 APPROVAL OF AGENDA
2427 Chilco RoadSite Coverage: 0.6% of lot area

Proposed Accessory Building for: Mr. G. WOODWORTH

Address: 2427 Chilco Road, View Royal, BC Design Firm: McNeil Building Designs Limited Date: 2017-06-17 Sheet: A1

General Specifications - Builder's Drawing Set

  1. Builder to check and verify all dimensions and conditions on job site and report any errors or omissions to the designer before proceeding with work.
  2. All work to comply with the current B.C. Building Code and all local by-laws.
  3. Concrete to be 20 MPa (3000 psi) at 28 days with 5-8% air entrainment.
  4. Footings to be on undisturbed soil or engineered fill with a minimum bearing capacity of 75 kPa (1500 psf).
  5. All lumber to be S-P-F #2 or better unless noted otherwise.
  6. Provide solid blocking at all point loads and under all interior partitions.
  7. All exterior walls to be 2x6 at 16" o.c. with R-20 insulation.
  8. All interior walls to be 2x4 at 16" o.c. unless noted otherwise.
  9. Roof framing to be as per manufacturer's truss design or as noted.
  10. Provide 1/2" GWB on all interior walls and ceilings.
  11. Provide continuous air/vapor barrier.
  12. All windows and doors to be installed as per manufacturer's instructions.
  13. All stairs to comply with B.C. Building Code requirements.

Architectural Views

3D View 1 showing a perspective rendering of the proposed accessory building structure
3D View 1 showing a perspective rendering of the proposed accessory building structure

Floor Plans

Site Layout and Property Data

Project Data

Category Detail
Zoning A-1 View Royal
Site Area 85,379 sf (0.795 Ha)
Site Coverage 598 sf + 4.9% = 12% (10% permitted)
Floor Areas Main: 510 sf
Loft: 108 sf
Total: 618 sf
Max Width or Length 7.5 m (4.5 m permitted)
Building Height Max permitted from AVG GRADE 5.9 m (*variance applied for)

Legend

  • (Elevation symbol) Denotes elevation.
  • (Anchor symbol) Denotes anchor.
  • (Utility pole symbol) Denotes utility pole.
  • (Tree symbol) Denotes approximate tree trunk, trunk diameter and species.

Site Plan Notes

  • SITE PLAN OF PART OF LOT 1, SECTION 98, ESQUIMALT DISTRICT, PLAN EPP45786.
  • All distances are in metres.
  • NOTE: Natural grade elevations are to geodetic datum. Geodetic datum is based upon information supplied by Associated Engineering Ltd.
  • Lot 1 is subject to covenants: Covenant CA4220998, Right of First Refusal CA4220999.
  • Chilco Road was Gazetted as Road March 13, 1924.
