Attachment 3 Site Plan – Michael E. Claxton Land Surveyor

REQUESTED VARIANCES

1. Siting of a principal building to the rear lot line from 7.5 m to 0.0m (deck is part of the principal building).
2. Separation of an accessory building from a principal building (deck) from 3.0m to 0.1m
3. Height of a fence from 2.0m to ~3.5m
4. Siting of an accessory building from a principal building from 1.2m to 0.1m
5. Separation of an accessory building (potting shed) from a principal building from 3.0m to 0.1m

Site Plan Notes

Proposed Addition to Residence for: Terry & Leslie Barry Address: 275 Plowright Road, View Royal, BC

Site Plan of: Lot 1, Plan 31815, Section 27, Esquimalt District Scale: 1:125 metric

Project Data:

• Lot Area: 717 sqm (7721 sqft)
• Zoning: R-1 Large Lot Residential
• New Lot Coverage:
  • Residence: 1502 + 28 + 32 sqft
  • Garage: 295 sqft
  • Total: 1857 sqft (24%)
• Floor Areas:
  • Main Ex: 945 sqft
  • Main New: 557 sqft
  • Sec Exist: 696 sqft
  • Sec New: 469 sqft
  • Total: 2667 sqft (max allow 3088.4 sqft)
• Building Height: Bldg Ht of New Addition: 22.7'

Variance Locations Identified on Plan:

1. Deck Extension
2. (Separation of accessory building from deck)
3. Fence
4. (Siting of accessory building)
5. Accessory Building (potting shed)
