Attachment 6 Accessory Building elevation

June 12, 2018Page 621 section

A technical drawing showing the elevation of the proposed 8' tall potting shed.

2. APPROVAL OF AGENDA
8 ft heightHardie Board finish

275 PLOWRIGHT ROAD - POTTING SHED

Hand-drawn technical sketch of a potting shed detailing dimensions and materials.
Hand-drawn technical sketch of a potting shed detailing dimensions and materials.

Building Specifications

  • Width: 8 ft.
  • Height: 8 ft.

Roof Details

  • Material: Corrugated Polycarbonate
  • Roof Pitch: 1.5 : 12, 12.5%
  • Structure: 2" x 6" Joists @ 24" OC
  • Depth/Overhang: 5 ft.

Wall Details

  • Upper Section: Clear Polycarbonate Panels
  • Lower Section: Hardie Board (White)
  • Framing: 2 x 4" x 4"
  • Accents: Battens (Black)
Page 62
