Double Sided Pylon Cabinet Sign Detail - Shaw

December 13, 2011Page 411 section

Design drawing for the proposed Shaw 'On Location' illuminated sign cabinet.

2 APPROVAL OF AGENDA
Dimensions: 8' 1" x 3' 0"

DOUBLE SIDED PYLON CABINET

Technical drawing and rendering of a double-sided pylon cabinet for "SHAW ON LOCATION". The diagram specifies dimensions of 8' - 1" wide by 3' - 0" high, with a side profile depth of approximately 14" to match existing structures.
Technical drawing and rendering of a double-sided pylon cabinet for "SHAW ON LOCATION". The diagram specifies dimensions of 8' - 1" wide by 3' - 0" high, with a side profile depth of approximately 14" to match existing structures.

Specifications (A)

  • ONE New D/S H/O fluorescent illuminated pylon cabinet
  • 3/16" thick, White acrylic faces with digital prints applied to plastic
  • Retainers & cabinets painted Black
  • Installed onto existing double pole pylon structure

File Name: - Shaw - McKaysSignage.pdf
Client Name Madman Mckay
Location 1681 Island Highway Victoria, BC
Start Date Nov 17 / 2011
Last Revision
Drawing# Mad Man McKays \ DS cabinet for PYLON.cdr
Page 1 of 4
Client Approval __________________________
Landlord Approval __________________________
Sales Rep Shawn Court
Designer Dave
Page 41
