Pylon Sign Elevation Drawing - 1681 Island Highway

December 13, 2011Page 421 section

Elevation drawing showing the existing pylon sign with the proposed new component.

2 APPROVAL OF AGENDA
Overall sign height: 19' 0"

DOUBLE SIDED PYLON CABINET

Technical drawing of a double-sided pylon sign with dimensions and labels for existing and new components. The sign features cabinets for "McKay's Home Theatre Centre," an LED matrix display, "Sharp," and a new addition for "Shaw On Location."
Technical drawing of a double-sided pylon sign with dimensions and labels for existing and new components. The sign features cabinets for "McKay's Home Theatre Centre," an LED matrix display, "Sharp," and a new addition for "Shaw On Location."

Sign Specifications

Existing Components:

  • 3' x 8' - 1" double sided, illuminated sign cabinet
  • LED matrix display
  • 18" x 8' - 1" double sided illuminated cabinet

New Component:

  • 3' x 8' - 1" double sided, illuminated sign cabinet

Structure and Dimensions:

  • Support Columns: 6" square HSS support columns
  • Total Height: 19' - 0"
  • Ground Clearance: 7' - 10" (from ground level to bottom of the lowest sign cabinet)

Project Information

Field Detail
Client Name Madman McKay
Location 1681 Island Highway Victoria, BC
Start Date Nov 17 / 2011
Last Revision
Drawing# Mad Man McKays 1 DS cabinet for PYLON.cdr
Page 2 of 4
Sales Rep Shawn Court
Designer Dave
Client Approval __________________________
Landlord Approval __________________________
Page 42
