Key Plan

Site plan for Rexall location #7103 at Admirals Walk, Victoria, BC. The plan illustrates the building footprint (41.2m x 26.7m), parking lot layout including small car stalls and landscaping zones, and the surrounding streets Glentana Road and Admirals Road. Callouts indicate the specific locations for various approved and proposed signage types.

Signage Status Callouts

Approved: rexall.ca
Approved: Rexall
Proposed:
Approved: rexall.ca
Proposed:
Approved: 20" A pharmacy first.
Approved: Rexall
Approved: 20" A pharmacy first.

Project Details

Item	Details
Vantage #:	REXA0001
Date:	3-MAR-10
Design #:	10-0258
Scale:	N.T.S.
Sales:	R. TRAHAN
Designer:	J. FOSTER

Revisions

Rev. #	Date
4a	14-JULY-11

Electrical Requirements

120V
347V

Project Location

Rexall #7103 ADMIRALS WALK VICTORIA, BC

Production Requirements

Conceptual artwork only
Vector Artwork Required
High Resolution Image Required
Final Colours Required

Legal and Contact Information

The artistic works depicted herein are copyright and are the exclusive property of Pattison Sign Group and as such cannot be reproduced in whole or in part without prior written consent.

Pattison Sign Group signs illuminated by fluorescent, Neon and/or HID Lamps contain Mercury (Hg). Dispose of these lamps according to Local, State, Provincial or Federal Laws.

PATTISON SIGN GROUP 555 Ellesmere Road Toronto, Ontario, Canada M1R 4E8 Tel: (416) 759-1111 Fax: (416) 266-4865 Toll Free: 1-800-268-5536 www.pattisonsign.com
