Building Elevations - Rexall Admirals Walk

December 13, 2011Page 521 section

Architectural elevation drawings showing the proposed sign placement on different building faces.

2 APPROVAL OF AGENDA

ELEVATIONS

Technical drawing illustrating building elevations and signage placements for a Rexall store located at Admirals Walk, Victoria, BC. The drawing includes West, East, North, and South elevations with dimensions and labels for approved and proposed signage.
Technical drawing illustrating building elevations and signage placements for a Rexall store located at Admirals Walk, Victoria, BC. The drawing includes West, East, North, and South elevations with dimensions and labels for approved and proposed signage.

West Elevation

  • Total Width: 41.2m
  • Height: 7.3m
  • Status: Approved signage shown.

East Elevation

  • Total Width: 41.2m
  • Height: 4.6m
  • Logo Dimensions: 20"
  • Status: Features both Approved and Proposed signage.

North Elevation

  • Total Width: 26.7m
  • Height: 4.8m
  • Status: Proposed signage shown.

South Elevation

  • Total Width: 26.7m
  • Height: 7.3m
  • Status: Features Approved signage and an "Alternate view of approved northeast corner." Signage includes "Rexall A pharmacy first." with 8" lettering.

Project Information

Field Details
Job No.
Vantage # REXA0001
Date 14-FEB-11
Design # 10-0258
Scale N.T.S.
Sales R. TRAHAN
Designer J. FOSTER
Revision # R4
Revision Date 14-JULY-11

Technical Requirements

  • Vector Artwork Required
  • High Resolution Image Required
  • Final Colours Required
  • Conceptual artwork only
  • Electrical Requirements:
    • 120V (Selected)
    • 347V
    • Other

Project Location

#7103 ADMIRALS WALK VICTORIA, BC MASTER

Contact Information

PATTISON SIGN GROUP 555 Ellesmere Road Toronto, Ontario, Canada M1R 4E8 Tel: (416) 759-1111 Fax: (416) 759-4965 Toll Free: 1-800-268-5535 www.pattisonsign.com

Legal Notices and Disclaimers

The artistic works depicted herein are copyright and are the exclusive property of Pattison Sign Group and as such cannot be reproduced in whole or in part without prior written consent.

Pattison Sign Group signs illuminated by fluorescent, neon and/or HID Lamps contain Mercury (Hg). Dispose of these lamps according to Local, State, Provincial or Federal Laws.

Approval

Customer Approval: ____________________ Date: ____________________
