Appendix
SCHEDULE 3 - 5 FT. OVAL SIGN DETAIL - APPROVED DVP 07/2011
December 13, 2011Page 591 section
Approved design specifications for the Rexall oval logo sign.
Approved September 6, 2011Sign area: 5.5m2
SCHEDULE 3: 5 FT. OVAL
Sign Layout and Installation
- X Represents attachment point
- X Represents electrical location
Technical Construction
- Custom rolled aluminum fascia
- Vertical supports - 52003
- 1 1/2" x 1 1/2" x 3/16" aluminum angle
- Grip flex retainer system c/w tensioning nut
- Illumination: 4 rows H.O. fluorescent lamps
- White flexible substrate with 3M vinyl graphics applied
- Transformer / ballast enclosure
- Aluminum back
Specifications
- Supply & install two (2) 54 sf illuminated fascia signs
- Frameless aluminum construction w/ flexible face
- 3M vinyl graphics face applied
- H.O. Daylight fluorescent illumination
- 50 SQ. FT / 5.00 AMPS @ 120V
- 6 ATTACHMENT POINTS
Colours
- White flexible substrate
- 3630-44 Orange (Pantone 1655 C)
- 3630-157 Sultan Blue (Pantone 288 C)
- Fillers pad. to match 3630-157 Sultan Blue (Pantone 288 C)
Project Information
| Field | Detail |
|---|---|
| Vantage #: | REXA0001 |
| Date: | 3-MAR-10 |
| Design #: | 10-0258 |
| Scale: | 3/8" = 1'-0" |
| Site: | A. TRAHAN |
| Designer: | J. FOSTER |
Electrical Requirements
- 120V
- 347V
- Other
Approval and Location Details
Town of View Royal Approved
- Date: SEP 6 2011
- Permit/File #: DVP 07/2011
- Name: COUNCIL
Project Location
- Rexall #7703
- ADMIRALS WALK
- VICTORIA, BC
Manufacturer Information
- Pattison Sign Group
- 555 Ellesmere Road, Toronto, Ontario, Canada M1R 4E8
- Tel: (416) 759-1111 | Fax: (416) 759-1565
- Toll Free: 1-800-268-6535
- www.pattisonsign.com
Page 59
