Approved design for 'A pharmacy first.' fascia lettering.

2 APPROVAL OF AGENDA
Approved September 6, 2011

SCHEDULE 4

"A PHARMACY FIRST." LETTERS

Technical drawing of "A pharmacy first." signage displaying dimensions of 5.5m (18'-1/2") in length, 0.5m height for lowercase letters, and 1'-8" height for the capital "A".
Technical drawing of "A pharmacy first." signage displaying dimensions of 5.5m (18'-1/2") in length, 0.5m height for lowercase letters, and 1'-8" height for the capital "A".

Note: Capital "A" height should always be 1/3 the height of accompanying Rexall oval.

Total Area: 2.75m2

Specifications:

  • Supply & install one (1) set of non-illuminated cut-out individual letters
  • 30mm thick PVC cut-out
  • Faces ptd. white
  • Returns ptd. to match 3M 3530-147 Lt. European Blue (Akzo-Nobel Rexall 472A-S8909N)
  • Letters pin-mounted to exterior wall

Colours:

  • Faces ptd. white
  • Returns ptd. to match 3M 3530-147 Lt. European Blue (Akzo-Nobel Rexall 472A-S8909N)

Project Information:

Field Detail
Vantage #: REXA0001
Date: 30-NOV-10
Design #: 10-2326
Scale: 3/16"=1'-0"
Sales: R. TRAHAW
Designer: J. FOSTER
Rev. #: R3
Date: 17-FEB-11

Location: Rexall #7103 ADMIRALS WALK VICTORIA, BC
