Approved design for alternate lettering placement for 'A pharmacy first.'

2 APPROVAL OF AGENDA
Approved September 6, 2011

SCHEDULE 5

"A PHARMACY FIRST." LETTERS

Technical drawing of signage text "A pharmacy first." with height dimensions of 0.5m (1'-3") and length dimensions of 5.5m (18'-1/2"), including a note stating: Capital "A" height should always be 1/3 the height of accompanying Rexall oval.
Technical drawing of signage text "A pharmacy first." with height dimensions of 0.5m (1'-3") and length dimensions of 5.5m (18'-1/2"), including a note stating: Capital "A" height should always be 1/3 the height of accompanying Rexall oval.

Specifications:

  • Supply & install one (1) set of non-illuminated cut-out individual letters
  • 30mm thick PVC cut-out
  • Faces & returns painted to match 3M 3630-147 Lt. European Blue (Akzo-Nobel Rexall 472N-SB90%)
  • Letters pin-mounted to exterior wall

Colours:

  • Faces & fillers painted to match 3M 3630-147 Lt. European Blue (Akzo-Nobel Rexall 472N-SB90%)

Project Information

Field Value
Vantage #: REXA0001
Date: 20-NOV-10
Design #: 10-2324
Scale: 3/8"=1'-0"
Sales: R. TRAHAN
Designer: J. FOSTER
Rev #: R2
Date: 15-FEB-11

Location: #7103 ADMIRALS WALK VICTORIA, BC

Town of View Royal Approval:

  • Approved: SEP 6 2011
  • Name: COUNCIL
  • Permit/File #: DVP 07/2011

Requirements Checklist:

  • Vector Artwork Required
  • High Resolution Image Required
  • Final Colours Required
  • Conceptual artwork only

Electrical Requirements:

  • 120V
  • 347V
  • Other
