Attachments for 14 Jedburgh Road DVP

September 13, 2016Pages 220–2235 sections

Maps and letters from Active Earth Engineering Ltd. regarding the Jedburgh Road frontage improvements variance.

2 APPROVAL OF AGENDA
Request to waive frontage improvements along the Island Highway

Report to Committee of the Whole Re: Development Variance Permit 2016/09 - 14 Jedburgh Rd Meeting Date: September 13, 2016

REVIEWED BY: Lindsay Chase MCIP RPP, Director of Development Services Deb Becelaere, Deputy Director of Engineering

ATTACHMENTS:

  1. Subject Property Map
  2. Applicant's Letter – Mike Achtem, P. Eng, PMP, Active Earth Engineering Ltd. July 20, 2016
  3. Tentative Plan of Subdivision – Active Earth Engineering Ltd.
  4. Exhibit A3, Transportation Master Plan, 2007
Page 220–223

Attachment 1. Property Location Map

Subject Property Map for 14 Jedburgh Rd showing surrounding lots and nearby streets including Island Highway and Helmcken Road
Subject Property Map for 14 Jedburgh Rd showing surrounding lots and nearby streets including Island Highway and Helmcken Road
Page 220–223

Attachment 2. Development Variance Permit Application Letter

Proposed Development at 14 Jedburgh Rd (9 Lot subdivision)

Project No. 1133 (AEE) Contract Title: 14 Jedburgh Rd Owner: Henry Louie c/o (Wayne Hopkins, Merdyn Developments)

This letter is written to request that any and all frontage improvements along the south frontage of 14 Jedburgh Road (along the Old Island Highway), be waived and eliminated. The owner will upgrade all other frontage along Jedburgh Road, and contribute the required DDC’s for the Old Island Highway frontage as per the PLA.

Certified by: Mike Achtem, P.Eng, PMP Contract Administrator July 20, 2016

Page 220–223

Attachment 3. Tentative Plan of Subdivision

Site Plan for proposed 9 lot subdivision at 14 Jedburgh Rd, View Royal
Site Plan for proposed 9 lot subdivision at 14 Jedburgh Rd, View Royal

Red Annotation in Site Plan: DEVELOPMENT VARIANCE APPLICATION: REQUESTING TO ELIMINATE ALL FRONTAGE IMPROVEMENTS ALONG THE OLD ISLAND HIGHWAY (SOUTH OF PROPOSED DEVELOPMENT AT 14 JEDBURGH RD)

Plan Details:

  • AEE PROJECT: 1133
  • ISSUED: JULY 2016
  • CIVIC ADDRESS: 14 JEDBURGH ROAD
  • LEGAL DESCRIPTION: LOT 10, BLOCK 1, SECTION 8 ESQUIMALT DISTRICT, PLAN 4074
Page 220–223

Attachment 4. Exhibit A3, Transportation Master Plan, 2007

Aerial view map titled View Royal Transportation Plan: Kissingbury Lane to Helmcken Road, showing planned road realignments and infrastructure changes
Aerial view map titled View Royal Transportation Plan: Kissingbury Lane to Helmcken Road, showing planned road realignments and infrastructure changes

Map Labels and Annotations:

  • Potential Rail Station Location
  • E&N Rail Trail Access - Provide Sidewalks
  • Re-align Intersection Approach
  • New Road Alignment
  • Existing Alignment
  • Consider Traffic Calming
  • Eliminate Right Turn Lane
  • Install Extruded Curb to Restrict Left Turns
  • Eliminate Traffic Circle

Exhibit Information:

  • DATE: AUG 15, 2007
  • DWG NAME: EXHIBIT A3
  • DRAWING NO: 5441.01-c
Page 220–223
