Committee of the Whole/Documents/Chilco Road Residential Grinder Pump Location Maps
Appendix

Chilco Road Residential Grinder Pump Location Maps

January 12, 2016Pages 166–1671 section

Aerial and technical maps showing the current location of grinder pumps and the proposed gravity sewer connection points on Chilco Road.

9.3.3 a) Chilco Road Residential Grinder Pump Conversion to Gravity System
Highlights 10 specific lots on Chilco Road north of Bamford Court

CHILCO ROAD RESIDENTIAL GRINDER PUMPS

Aerial map of the Chilco Road residential area, with a red outline highlighting properties currently on sanitary grinder pumps. The map identifies various landmarks including Mill Hill Regional Park, Robin Hill Park, Chilco Park, and the Galloping Goose Regional Trail.
Aerial map of the Chilco Road residential area, with a red outline highlighting properties currently on sanitary grinder pumps. The map identifies various landmarks including Mill Hill Regional Park, Robin Hill Park, Chilco Park, and the Galloping Goose Regional Trail.

Map Callout:

  • Chilco Road residents currently on Sanitary Grinder Pumps

Important

This map is for general information purposes only. The Capital Regional District (CRD) makes no representations or warranties regarding the accuracy or completeness of this map or the suitability of the map for any purpose. This map is not for navigation. The CRD will not be liable for any damage, loss or injury resulting from the use of the map or information on the map and the map may be changed by the CRD at any time.

Printed Thu, Jan 7, 2016

Detailed site plan of Chilco Road showing specific residential lots highlighted in red, with lot numbers, technical survey markers, and square meterage for adjacent lots.
Detailed site plan of Chilco Road showing specific residential lots highlighted in red, with lot numbers, technical survey markers, and square meterage for adjacent lots.

Residential Lot Numbers (Highlighted):

  • 2460
  • 2396
  • 2392
  • 2388
  • 2384
  • 2380
  • 2376
  • 2391
  • 2387
  • 2383

Additional Lot Information:

  • 2372 (531 sq.m.)
  • Lot 36 (504 sq.m.)
  • Lot 37 (474 sq.m.)
  • Lot 38 (419 sq.m.)

Technical Markers and Labels:

  • CHILCO ROAD
  • DMH
  • DMH 3
  • TH5245
  • TH5241
  • OIP5148
  • 42 DR PE
  • 200' FIR
  • 300' FIR
  • 1100' FIR
Page 166–167
