Attachment 5: Site Plan (Sheet A1.2)

December 13, 2016Page 401 section

Detailed site plan showing building footprints, courtyard parking, and proximity to Trans-Canada Highway.

6.4.3.a Development Permit No. 2016/13 - 450 Six Mile Road - "Pacific Lakeside"
Proposed building heights: 12.0m

Pacific Lakeside - Proposed Rental Apartment Development

Site Plan

450 Six Mile Road, View Royal, BC

Architectural site plan for a proposed rental apartment development at 450 Six Mile Road, detailing Building A, Building B, parking layouts, landscaping, and adjacent property lines.
Architectural site plan for a proposed rental apartment development at 450 Six Mile Road, detailing Building A, Building B, parking layouts, landscaping, and adjacent property lines.

Project Details:

  • Address: 450 Six Mile Road, View Royal, BC
  • Architect: Joe Newell Architect Inc.
  • Sheet Number: A1.2
  • Date: 2018.10.31

Plan Features:

  • Building A: Main Entrance Level 1 (30.02m elevation), featuring Courtyard Parking with 8 parking stalls.
  • Building B: Main Entrance Level 1 (30.1m elevation).
  • Access: Presley Place (private road) providing access to the site.
  • Context: The site is bordered by the Trans Canada Highway to the north.
  • Property Boundaries:
    • Lot 9 (Plan VIS601, 026-789-175)
    • Lot 8 (Plan VIS601, 026-789-167)
    • Lot 7 (Plan VIS601, 026-789-159)
  • Site Specifications:
    • Scale: 1:200
    • Various setbacks indicated, including 4.0m (13'-1 1/2"), 6.0m (19'-8 1/4"), and 7.5m (24'-7 1/4").
    • Ramp gradients noted at 11.7%, 6.7%, and 3.3%.
    • Includes locations for garbage/recycling, existing concrete retaining walls, and new concrete retaining walls.
