Committee of the Whole/Documents/Attachment 6: Lower Parkade Plan - Building A (Sheet A2.1)
Appendix

Attachment 6: Lower Parkade Plan - Building A (Sheet A2.1)

December 13, 2016Page 411 section

Architectural plan for the lower parkade of Building A, showing parking stalls and bicycle storage.

6.4.3.a Development Permit No. 2016/13 - 450 Six Mile Road - "Pacific Lakeside"
67 stalls provided69 bicycle spaces

Pacific Lakeside - Proposed Rental Apartment Development

450 Six Mile Road, View Royal, BC

Lower Parkade Plan - Building A

Scale: 1:100 Total Parkade Area: 1,091.4 m² | 11,747.7 sq.ft.

Architectural drawing of the Lower Parkade Plan for Building A, illustrating 33 parking stalls, a bicycle room, ramps, and utility spaces including garbage/recycling and elevator machine rooms.
Architectural drawing of the Lower Parkade Plan for Building A, illustrating 33 parking stalls, a bicycle room, ramps, and utility spaces including garbage/recycling and elevator machine rooms.

Parking

  • 9 x 1 = 9
  • 10 x 1 = 10
  • 14 x 1.5 = 21
  • 14 x 1.5 = 21
  • 4 x 1.5 = 6

67 stalls required

  • lower level parking: 33 stalls (including 18 small car)
  • upper level parking: 26 stalls (including 2 small car)
  • courtyard parking: 8 visitor stalls

67 stalls provided

  • 69 bicycle spaces in secure room

Plan Components and Notations

  • Lower Parking: 33 parking stalls (various stalls designated as "Small Car only")
  • Bicycle Room: 69 bicycles
  • Garbage and Recycling
  • Elevator Machine Room
  • Lobby: 32.91m
  • 4.7 % ramp down
  • 2 % ramp down
  • Line of building above (indicated by dashed red line)

Sheet Information

  • Sheet: A2.1
  • Date: 2018.10.02
Page 41
