Attachment 7: Main Floor Plan - Building A (Sheet A2.2)

December 13, 2016Page 421 section

Main floor architectural plan for Building A, showing unit layouts and upper parking.

6.4.3.a Development Permit No. 2016/13 - 450 Six Mile Road - "Pacific Lakeside"
Total Floor Area: 1,059.7 m2

Pacific Lakeside - Proposed Rental Apartment Development

450 Six Mile Road, View Royal, BC

Main Floor Plan - Building A

Scale 1:100

Architectural floor plan for the main floor of Building A, showing residential units 101-108, utility rooms, an entry courtyard with visitor parking, and a large upper parking area.
Architectural floor plan for the main floor of Building A, showing residential units 101-108, utility rooms, an entry courtyard with visitor parking, and a large upper parking area.

Building Statistics:

  • Total Floor Area: 1,059.7 m² / 11,406.9 sq.ft.
  • Total Parkade Area: 715.5 m² / 7,701.6 sq.ft.

Residential Units:

  • Unit 101: Suite Type A
  • Unit 102: Suite Type F
  • Unit 103: Suite Type K
  • Unit 104: Suite Type E
  • Unit 105: Suite Type F
  • Unit 106: Suite Type F
  • Unit 107: Suite Type G
  • Unit 108: Suite Type Ia

Common and Utility Areas:

  • Main Entrance: 36.02m
  • Mechanical Room
  • Elec. Room
  • Building Storage
  • Garbage and Recycling Area
  • Storage Lockers (multiple locations)
  • Elevators (2)
  • Stairwells
  • Hydro Area

Parking and Site Details:

  • Entry Courtyard: 8 visitor stalls
  • Upper Parking: 26 stalls (including stalls designated for small cars only)
  • Line of building above indicated over parking area
  • Landscaped areas and entry courtyard features
Page 42
