Committee of the Whole/Documents/Attachment 11: Third Floor Plan - Building A (Sheet A2.4)
Appendix

Attachment 11: Third Floor Plan - Building A (Sheet A2.4)

December 13, 2016Page 461 section

Architectural layout for the third floor of Building A.

6.4.3.a Development Permit No. 2016/13 - 450 Six Mile Road - "Pacific Lakeside"
Total Floor Area: 1,716.8 m2

Pacific Lakeside - Proposed Rental Apartment Development

450 Six Mile Road, View Royal, BC

Third Floor Plan - Building A

Architectural drawing A2.4 showing the Third Floor Plan for Building A, including floor layout for units 301 through 315, elevator lobby, storage lockers, and dimensional details.
Architectural drawing A2.4 showing the Third Floor Plan for Building A, including floor layout for units 301 through 315, elevator lobby, storage lockers, and dimensional details.

Total Floor Area: 1,716.8 m² | 18,479.5 sq.ft. Scale: 1:100 Date: 2018.10.27 Drawing Number: A2.4

Unit List:

Unit Number Suite Type
Unit 301 Suite Type H
Unit 302 Suite Type Jb
Unit 303 Suite Type B
Unit 304 Suite Type B
Unit 305 Suite Type C
Unit 306 Suite Type B
Unit 307 Suite Type F
Unit 308 Suite Type Gb
Unit 309 Suite Type Ga
Unit 310 Suite Type E
Unit 311 Suite Type K
Unit 312 Suite Type F
Unit 313 Suite Type F
Unit 314 Suite Type Ib
Unit 315 Suite Type G

Additional Floor Areas and Features:

  • Elevator Lobby (41.95 m)
  • janitor
  • mech. shaft
  • electrical mech. shaft
  • 7 storage lockers
  • 9 storage lockers
Page 46
