Committee of the Whole/Documents/Attachment 16: South Elevation - Building A (Sheet A3.1)
Appendix

Attachment 16: South Elevation - Building A (Sheet A3.1)

December 13, 2016Page 511 section

External elevation drawing showing the southern facade (main entrance) of Building A.

6.4.3.a Development Permit No. 2016/13 - 450 Six Mile Road - "Pacific Lakeside"
Material key includes fibre cement siding and cedar trellises

Pacific Lakeside - Proposed Rental Apartment Development

450 Six Mile Road, View Royal, BC

Building A - Elevations

South (Main Entrance) Elevation of Building A and a secondary elevation view, including a Materials Key and building height specifications.
South (Main Entrance) Elevation of Building A and a secondary elevation view, including a Materials Key and building height specifications.

South (Main Entrance) Elevation - Building A Scale: 1:100

Building Heights

Level Metric Elevation Imperial Elevation
US Roof Trusses - Top of Wall Plate 14.33 m (47' - 0 1/8")
Fourth Floor FFL - Top of Concrete 11.60 m (38' - 0 11/16")
Third Floor FFL - Top of Concrete 9.04 m (29' - 8")
Second Floor FFL - Top of Concrete 6.25 m (20' - 6 1/4")
AVERAGE GRADE (Datum 36.57m) 3.11 m (10' - 2 1/2")
Main Floor FFL - Top of Concrete 3.12 m (10' - 2 3/4")
Parkade FFL - Top of Slab (Datum 33.45m) 0.0 m (0' - 0")

Materials Key

Key Item Description Color
1 Roof Fascia Combed Spruce - Painted BM HC-168 Chelsea Gray
2 Cross Cavity Flashing Pre-finished Metal Flashing 'Galvalume'
3 Slab Edgeband Combed Spruce - Painted BM HC-168 Chelsea Gray
4 Roofs Torch-on Membrane/Sheet Metal Black / 'Galvalume'
5 Soffits Perforated Aluminum 'Galvalume'
6 Fibre Cement Siding 6" Exposure Horizontal Siding - Stained Rustic Series 'Stone Blue'
7 Fibre Cement Siding 6" Exposure Horizontal Siding - Stained Rustic Series 'Mountain Cedar'
8 Fibre Cement Siding Smooth Panel BM HC-169 Coventry Gray
9 Exposed Concrete Reveal Lines as Shown - Painted BM HC-169 Coventry Gray
10 Windows Vinyl Window Frames White
11 Window / Door Trim Combed Spruce - Painted Rustic Series 'Slate Gray'
12 Window / Door Trim Combed Spruce - Painted Rustic Series 'Mountain Bark'
13 Exterior Doors Fiberglass - Painted BM HC-168 Chelsea Gray
14 Deck Fascia Combed Spruce - Painted / Metal Flashing BM HC-168 Chelsea Gray / Galvalume
15 Deck Railing Pre-finished Aluminum Black
16 Trellis / Fencing / Posts Cedar Cedar Semi-Transparent Stain

Drawing Information

  • Sheet Number: A3.1
  • Date: 2016.10.07
Page 51
Extracted from: 2016 12 13 Committee of the Whole Agenda - Agenda - Pdf
