Committee of the Whole/Documents/Attachment 19: Parking & Floor Plans - Building B (Sheet A4.1)

Appendix

Attachment 19: Parking & Floor Plans - Building B (Sheet A4.1)

December 13, 2016Page 541 section

Detailed floor and parking plans specifically for the smaller 9-unit Building B.

6.4.3.a Development Permit No. 2016/13 - 450 Six Mile Road - "Pacific Lakeside"

Building B total area: 342.3 m2

Pacific Lakeside - Proposed Rental Apartment Development

450 Six Mile Road, View Royal, BC

Architectural drawing sheet A4.1 containing four floor plan diagrams for Building B, including parking, first, second, and third floor levels.

Building B - Floor Area Summary

Plan Title	Total Floor Area (m²)	Total Floor Area (sq. ft.)
Building B - Parking / Main Entrance	45.4 m²	489 sq. ft.
Building B - First Floor Plan	342.3 m²	3,684 sq. ft.
Building B - 2nd Floor Plan	342.3 m²	3,684 sq. ft.
Building B - Third Floor Plan	324.3 m²	3,492 sq. ft.

1. Building B - Parking / Main Entrance

Parking Details:
- 14 stalls provided (including 4 small cars)
- 14 stalls required (9 x 1.5 = 13.5)
- 12 bicycle spaces in secure rooms
Key Features:
- Main Entrance (FFL = 30.1m)
- Electrical room
- Visitor parking
- 5% slope down

2. Building B - First Floor Plan

Residential Units:
- Unit 101 - Suite Type R
- Unit 102 - Suite Type R
- Unit 103 - Suite Type R
Common Areas:
- Lobby (FFL = 32.66m)
- Elevator mechanical room
- Storage area
- Stairs

3. Building B - 2nd Floor Plan

Residential Units:
- Unit 201 - Suite Type R
- Unit 202 - Suite Type R
- Unit 203 - Suite Type R
Common Areas:
- Lobby
- Mechanical Room
- Stairs

4. Building B - Third Floor Plan

Residential Units:
- Unit 301 - Suite Type S
- Unit 302 - Suite Type S
- Unit 303 - Suite Type S
Common Areas:
- Lobby
- Mechanical Room
- Stairs

Architect: Joe Newell Architect
Date: 2018.10.27
Sheet Number: A4.1

Page 54
