Attachment 20: Roof Plan & Suite Types - Building B (Sheet A4.2)

Pacific Lakeside - Proposed Rental Apartment Development

Address: 450 Six Mile Road, View Royal, BC
Drawing Number: A4.2
Date: 2016.10.01

1. Roof Plan - Building B

• Scale: 1:100
• Plan displays a central "flat roof area" and several sections with a "1.5:12 Slope".

2. Suite Type - R

• Scale: 1:100
• Total Floor Area: 88.6 m² | 954 sq.ft.
• Suite Details:
  • Kitchen: 8'-0" x 11'-7"
  • Bedroom: 13'-1" x 10'-0"
  • Bedroom: 11'-1" x 8'-6"
  • Deck: 9'-0" x 16'-0"
  • Layout includes: Entry, kitchen, laundry/dryer area (L/D), living/dining area, two bedrooms, and a bathroom.

3. Suite Type - S

• Scale: 1:100
• Total Floor Area: 84.3 m² | 907.7 sq.ft.
• Suite Details:
  • Kitchen: 7'-0" x 12'-11"
  • Bedroom: 12'-1" x 11'-8"
  • Bedroom: 10'-3" x 8'-6"
  • Deck: 6'-0" x 21'-4"
  • Layout includes: Entry, kitchen, laundry/dryer area (L/D), living/dining area, two bedrooms, and a bathroom.
