Attachment 22: Site Sections (Sheet A6.1)

Pacific Lakeside - Proposed Rental Apartment Development

450 Six Mile Road, View Royal, BC

Date: 2018 10 07 Drawing No: A6.1

1 Site Section

Scale: 1:150

This section shows the overall site profile including both Building A and Building B relative to the site grade and parkade levels.

Site Elevations and Floor Levels:

• U/S Roof Trusses - Top of Wall Plate: 14.20m (46' 7 1/8")
• Fourth Floor FFL - Top of Concrete: 11.08m (36' 4 1/4")
• Third Floor FFL - Top of Concrete: 8.52m (27' 11 1/2")
• Second Floor FFL - Top of Concrete: 5.93m (19' 5 1/2")
• Average Grade (Datum: 36.35m)
• Main Floor FFL - Top of Concrete: 3.12m (10' 2 3/4")
• Parkade FFL - Top of Slab: 0.0m (El. (Datum) 32.55m)

2 Building Section - Building A

Scale: 1:100

A longitudinal section through Building A detailing suite types, storage areas, and floor heights.

Vertical Dimensions:

• Main Floor to Second Floor: 2.81m (9' 2 3/4")
• Second Floor to Third Floor: 2.59m (8' 5 7/8")
• Third Floor to Fourth Floor: 2.56m (8' 4 3/4")
• Fourth Floor to Roof Wall Plate: 3.12m (10' 2 7/8")

Interior Designations:

• Level 1: Mechanical Room, Storage Lockers, 1 Bedroom+Den Suite, 2 Bedroom Suite, 2 Bedroom+Den Suite.
• Level 2: Corridor, Storage Lockers, 1 Bedroom+Den Suite, 2 Bedroom Suite, 2 Bedroom+Den Suite.
• Level 3: Corridor, Storage Lockers, 1 Bedroom+Den Suite, 2 Bedroom Suite, 2 Bedroom+Den Suite.
• Level 4: Corridor, Storage Lockers, 1 Bedroom+Den Suite, 2 Bedroom Suite, 2 Bedroom Suite.

3 Building Section - Building B

Scale: 1:100

A transverse section through the lobby and elevator core of Building B.

Elevations:

• U/S Roof Trusses - Top of Wall Plate: 10.95m (35' 11 1/8")
• Third Floor FFL - Top of Concrete: 8.52m (27' 11 1/2")
• Second Floor FFL - Top of Concrete: 5.55m (18' 2 1/2")
• Main Floor FFL - Top of Concrete: 2.74m (9' 0")
• Average Grade (Datum: 36.35m)
• Parkade FFL - Top of Slab: 0.0m (El. (Datum) 32.55m)

Interior Designations:

• Elevator Lobby and 1 Bedroom Suites on Main, Second, and Third floors.

4 Building Section - Building B

Scale: 1:100

A transverse section through a typical suite wing of Building B.

Elevations:

• U/S Roof Trusses - Top of Wall Plate: 10.95m (35' 11 1/8")
• Third Floor FFL - Top of Concrete: 8.52m (27' 11 1/2")
• Second Floor FFL - Top of Concrete: 5.55m (18' 2 1/2")
• Main Floor FFL - Top of Concrete: 2.74m (9' 0")
• Average Grade (Datum: 36.35m)
• Parkade FFL - Top of Slab: 0.0m (El. (Datum) 32.55m)

Interior Designations:

• 1 Bedroom and 2 Bedroom Suites on Main, Second, and Third floors above the Parkade level.
