Committee of the Whole/Documents/DP 2016/14 - Attachment 5. DP1.1 – Building Section and Site Details
Appendix

DP 2016/14 - Attachment 5. DP1.1 – Building Section and Site Details

January 10, 2017Page 641 section

Cross-sectional drawings of the North Building showing floor heights and parkade levels.

2. APPROVAL OF AGENDA

Eagle Creek Village Phase 2 - North Bldg

North Building Site Sections

Architectural drawing DP1.1 showing two site sections (1 and 2) of the North Building with floor levels, elevations, and ramp grades.
Architectural drawing DP1.1 showing two site sections (1 and 2) of the North Building with floor levels, elevations, and ramp grades.

1 SITE SECTION

Scale: 1:150

Elevation Description
119.00 T.O. PARAPET
115.71 T.O. ROOF JOIST
112.62 T.O. FOURTH FLOOR
109.53 T.O. THIRD FLOOR
106.44 T.O. SECOND FLOOR
103.35 T.O. MAIN FLOOR SLAB
100.00 T.O. PARKADE FLOOR 01
97.00 T.O. PARKADE FLOOR 02

Section Details:

  • Building Height: 21.56m building height above calculated avg. grade
  • Average Calculated Grade: El. 97.44
  • Parkade Ramp: 12.3% Grade
  • Floor Labels: 4th Floor, 3rd Floor, 2nd Floor, Main Floor, Upper Parkade & Entrance, Lower Parkade (L2)
  • Site Markers: Property Line, Setback

2 SITE SECTION

Scale: 1:150

Elevation Description
118.43 T.O. PARAPET
115.71 T.O. FIFTH FLOOR
112.62 T.O. FOURTH FLOOR
109.53 T.O. THIRD FLOOR
106.44 T.O. SECOND FLOOR
103.35 T.O. MAIN FLOOR SLAB
100.00 T.O. PARKADE SLAB
97.00 T.O. PARKADE FLOOR 02

Section Details:

  • Building Height: 21.08m building height above calculated avg. grade
  • Average Calculated Grade: El. 97.35
  • Parkade Entrance: 15% Grade
  • Floor Labels: 5th Floor, 4th Floor, 3rd Floor, 2nd Floor, Main Floor, Upper Parkade (L2) & Main Entrance, Lower Parkade
  • Site Markers: Property Line, Line of Building

Project Information

  • Firm: Omicron Architecture Engineering Ltd.
  • Project Name: Eagle Creek Village Phase 2 - North Bldg
  • Project Number: 11 14 032
  • Drawing Number: DP1.1
  • Drawn: RI
  • Checked: IM
  • Date: November 09, 2016
Page 64
