DP 2016/14 - Attachment 7. DP2.1 – Main Floor / Parking L1 Plan

January 10, 2017Page 661 section

Floor plan for the ground level including additional parking and the main lobby entrance.

2. APPROVAL OF AGENDA
49 car spaces on level L1

Eagle Creek Village Phase 2 - North Bldg

North Building Main Floor / Parking L1

Detailed architectural floor plan for the Main Floor and Parking Level L1 of the North Building, illustrating parking stall arrangements, mechanical rooms, lobby area, vertical circulation, and vehicle ramps.
Detailed architectural floor plan for the Main Floor and Parking Level L1 of the North Building, illustrating parking stall arrangements, mechanical rooms, lobby area, vertical circulation, and vehicle ramps.

Main Floor Plan Summary

  • Scale: 1:100
  • Main Floor / Parking Floor Plan Area: 1,605 M² [17,276 SQ.FT]
  • Parking Stalls: 49

Identified Rooms and Areas

  • Storage
  • Small Car Parking Stalls
  • Electrical Room
  • Water Main Mechanical Room
  • Lobby
  • Building Entrance
  • Ramp Down to L2 Parkade
  • Ramp Up
  • Carpark Entrance
  • Stair 1
  • Elevator (ELEV)

Plan Annotations

  • Provide min. 2.1m overhead clearance (indicated at multiple access points and stall areas)
  • Fire alarm annunciator
  • Mail boxes
  • 24 Lockers (located near Stair 1)
  • 22 Lockers (located near the mechanical rooms)
  • Fire department connection
  • Entry phone / HC push button

Project Data

  • Project Number: 11 14 032
  • Date: Nov. 16, 2016
  • Drawn By: RI
  • Checked By: IM
  • Drawing Number: DP2.1
  • Status: NOT FOR CONSTRUCTION

Revision History

No. Date Remarks
1 NOV. 16, 2016 ISSUED FOR DP
Page 66
